Power supply for LED strips - 12V / 29A / 350W

Index: PRO-18507 EAN: 5900804092056
BOTLAND B. DERKACZ SPÓŁKA JAWNA Opinie z ekomi-pl.com

A mounting power supply unit with which it is possible to supply power to strips and LED strips. The supply voltage ranges from 175 V to 240 V AC. The output voltage is 12 V DC and the output current is 29 A. The power supply is equipped with a terminal strip and a fan. The power supply is equipped with a terminal strip and a fan. It has 2 input channels and numerous protections.

€27.88
€22.67 tax excl.

Available
(Check quantity)
Shipping in 24 hours
30-day returns
PayPal payment
Manufacturer: OEM

Product description: Mounting power supply for LED strips and straps 12V / 29A / 350W

A mounting power supply unit with which it is possible to supply power to strips and LED strips. The supply voltage ranges from 175 V to 240 V AC. The output voltage is 12 V DC and the output current is 29 A. The power supply is equipped with a terminal strip and a fan. The power supply is equipped with a terminal strip and a fan. It has 2 input channels and numerous protections.

Technical specifications of the Switch Mode Power Supply

  • Model: CP12350B20
  • Power supply type: impulse, mounting
  • Maximum power: 350 W
  • Output voltage: 12 V DC
  • Output current: 29 A
  • Supply voltage: 175 V to 240 V AC / 50 / 60 Hz
  • Electrical connection: terminal strip
  • Security:
    • Against overload
    • Before the tension increases
    • Before a short circuit
  • Installation: to be built in
  • Number of entrances: 2
  • Operating temperature: -25°C to 70°C
  • Dimensions: 200 x 99 x 40 mm
Zasilacz montażowy 12 V DC / 29 A.
12 V DC / 29 A mounting power supply unit.



Nominal output voltage 12.0 V
Nominal power 350 W
