Current Sensor ACS723 - SparkFun SEN-13679

Index: SPF-12373
BOTLAND B. DERKACZ SPÓŁKA JAWNA Opinie z ekomi-pl.com

Current sensor operating in the range from 10 mA to 5 A on the basis of Hall effect. The output is an analog voltage. The supply voltage is 5 V.

PLN32.44
PLN32.44 tax excl.
Waiting time approx. 4-6 weeks
Waiting for delivery
30-day returns
PayPal payment
Manufacturer: SparkFun
Compatibility: Arduino

Description

Current sensor operating in the range from 10 mA to 5 A on the basis of Hall effect. The output is an analog voltage. The supply voltage is 5 V.

SparkFun Current Sensor Breakout - ACS723

The module can measure direct current and alternating current in the range of up to 5 A, and its basic sensitivity is 400 mV / A. Default sampling rate is 20 kHz.

Pins

The module has the following pins:

SparkFun Current Sensor Breakout - ACS723 Low Current

Pin Description
VCC The supply voltage is 5 V.
VOUT

The output voltage is proportional to the current

IP+ and IP-.

GND The ground of the system.
IP + The input of the current sensor.
IP - The input of the current sensor.

Specification

  • Supply voltage: 5 V
  • Analog output
  • Current measurement: from 10 mA to 5 A
  • Sampling rate: 20 kHz (the possibility of setting to 80 kHz)
  • Chip: ACS723
  • Complete electrical isolation of the control signal, from the measured current
  • Basic sensitivity without amplification: 400 mV / A
  • Module dimensions: 24 x 15 mm
