Arducam Pivariety 21MPx IMX230 camera module - for Raspberry Pi 4B/3B+/2B/3A+/Zero/CM3/CM4

Index: ACM-19882
BOTLAND B. DERKACZ SPÓŁKA JAWNA Opinie z ekomi-pl.com
Arducam Pivariety camera module designed for Raspberry Pi version Pi 4B / 3B+ / 2B / 3A+ / Zero and version CM3 / CM4. The camera uses ISP hardware functions. It offers users automatic white balance, lens shadow correction, programmable focus control. The maximum frame rate is 9 frames per second at 5344 x 4012 px.
PLN405.69
PLN405.69 tax excl.
On request. Waiting time 4-6 weeks.
Waiting for delivery
30-day returns
PayPal payment
Manufacturer: ArduCam
Compatibility: Raspberry Pi

Product description: Arducam Pivariety 21MPx IMX230 camera module for Raspberry Pi 4B / 3B+ / 2B / 3A+ / Zero / CM3 / CM4

Arducam Pivariety camera module is designed for Raspberry Pi 4B / 3B+ / 2B / 3A+ / Zero and CM3 / CM4 version. The camera uses ISP hardware functions. It offers users automatic white balance, lens shadow correction, programmable focus control. The maximum frame rate is 9 frames per second at 5344 x 4012 px.

Moduł kamery Arducam Pivariety.

Arducam Pivariety Camera Module.

This product is compatible with Raspberry Pi!

ArduCam manufacturer provides a detailed user guide that makes getting started with the camera much easier.

Wyposażona w 21-megapikselowy czujnik koloru marki Sony.

Equipped with a 21-megapixel color sensor from Sony.

Special features of Arducam Pivariety camera module

  • Equipped with 21 megapixel color sensor Sony - IMX230 Exmor RS
  • Automatic exposure control and automatic white balance
  • Programmable focus control
  • Support for Gstreamers
  • Used in UAV drone, defect detection and face recognition scenarios

Kit contents

  • Arducam Pivariety 21 MPx IMX230 camera module
  • ArduCam adapter
  • FPC 15-pin terminal strip - 200 mm
  • FPC 15-pin (1 mm pitch) to 20-pin (0.5 mm pitch) connection tape - 73 mm
  • Transparent cap and mounting accessories

Technical specification of the camera from ArduCam

  • Camera is compatible with Raspberry Pi board versions 4B / 3B+ / 2B / 3A+ / Zero / CM3 / CM4
  • Sensor: IMX230
  • Matrix: 21 MPx
  • Pixel size: 1.12 µm x 1.12 µm
  • Optical format: 1/2.4''
  • Maximum frame rate: 9 frames per second at 5344 x 4012 px
  • Lens Specifications:
    • focal length: 4.77 mm
    • F.NO: 1.75 ± 5%
    • FOV angle: 64° (horizontal)
  • IR sensitivity: integrated filter
  • Focus mode: programmable focus control
  • Recording modes:
    • 5344 x 4012 / 9 fps
    • 3840 x 2160 / 10 fps
    • 2592 x 1944 / 15 fps
    • 2656 x 2004 / 30 fps
    • 1920 x 1080 / 30 fps
    • 1280 x 960 / 120 fps
    • 1280 x 720 / 120 fps
    • 640 x 480 / 120 fps
  • Sensor output format: RAW10
  • Output interface: 2-core MIPI
  • Output Format:
    • image format: JPG, YUV420, RAW, DNG
    • video format: MJPEG, H.264
  • Element dimensions: 38 x 38 mm
Wysokość kamery z nakładką wynosi 62 mm.

The height of the camera with the cap is 62 mm.
