SparkFun OpenLog Artemis is an open source data logger . The module is pre- programmed to automatically record GPS data, UART serial data, and a wide range of pressure, humidity and distance sensors. OpenLog Artemis by SparkFun automatically detects , configures and registers sensors of the Qwiic ecosystem.
SparkFun OpenLog Artemis - data logger - version without IMU - SparkFun DEV-19426
€45.00
€36.59 tax excl.
Available
Shipping in 24 hours
PayPal payment
Manufacturer: SparkFun

Product description: SparkFun OpenLog Artemis - data logger - version without IMU - SparkFun DEV-19426

SparkFun OpenLog Artemis is an open source data logger . The module is pre- programmed to automatically record GPS data, UART serial data, and a wide range of pressure , humidity and distance sensors. OpenLog Artemis by SparkFun automatically detects , configures and records sensors of the Qwiic ecosystem. Incoming serial data is automatically saved to the file at a baud rate of up to 500,000 bps . Data are saved on a microSD memory card (the card must be purchased separately and inserted into the slot on the board). Artemis also allows analog data recording via four ADC inputs. Voltages up to 2 V can be recorded with 14-bit precision, up to 1900 Hz for one channel and 1000 Hz for all four channels. What's more, the module has a built-in real time clock RTC, thanks to which all data can be marked with the login time.

More information about the module can be found in the user guide prepared by the manufacturer!

SparkFun OpenLog Artemis - rejestrator danych - wersja bez IMU - SparkFun DEV-19426. SparkFun OpenLog Artemis - data logger - version without IMU - SparkFun DEV-19426.

Rejestrator danych typu open source od SparkFun. Open source data logger from SparkFun.

Technical specification of the module

  • SparkFun OpenLog Artemis module - Apollo3 microcontroller based on Cortex-M4F
    • Configurable via USB CH340E driver and Artemis Firmware Upload GUI
  • Operating voltage range: 3.3 V to 6.5 V (via VIN pin with optional external power switch)
    • 5V from USB
    • 3.6 V to 4.2 V from Li-Pol battery (via VBATT or 2-pin JST)
      • Minimum charging speed: 450 mA
  • Power consumption
    • ~ 20 mA (run)
    • ~ 80 µA (sleep)
    • ~ 18 µA (Deep Sleep - regulator off)
  • Board outputs
    • 1x USB Type-C
    • 1x Li-Pol battery connector
    • 1x Qwiic
    • 1x SWD 2x5
    • 4x ADC
      • 14-bit, up to 1900 Hz, maximum voltage 2 V (compatible with 3.3 V)
    • Series
      • Logging speed up to 500000bps
    • 1x microSD memory card slot
      • Support for FAT32 and older FAT16 formats up to 32 GB with power control
  • RTC 1 mAh
  • LED diodes
    • Power
    • Li-Pol charge indicator
    • Serial Tx and Rx
    • Status
Package width 5 cm
Package height 1 cm
Package depth 9 cm
Package weight 0.006 kg
