iNode Care Sensor 4 - motion, temperature and magnetic field

Index: INO-09936 EAN: 5904422314668

iNode Care Sensor 2 is a precise wireless motion, temperature, and magnetic field sensor with built-in data recorder. Designed mainly for home automation and elderly care. It allows you to detect the motion of objects, to which it is attached, e.g. doors, windows, medication boxes.

€23.98
€19.50 tax excl.
Waiting for confirmation of delivery date
Product unavailable
30-day returns
PayPal payment
Manufacturer: iNode

Description

iNode Care Sensor 2 is a precise wireless motion, temperature, and magnetic field sensor with built-in data recorder. Designed mainly for home automation and elderly care. It allows you to detect the motion of objects, to which it is attached, e.g. doors, windows, medication boxes. It also enables you to determine the position in relation to the plane of the Earth. iNode Care Sensor 4 will be a great addition to your smart home.

It has the function of activating an LED signal when within the reach of the scanning device.

The device status (temperature and position) is sent online to the transmission frame every 0.3 - 10 seconds and can be archived in the device memory. The device can work with iNode Care Relay. The software allows you to set an alarm, which will result in turning on / off an external device.

Check how to useiNode!

Software:

Apps for ANDROID and WINDOWS. Configuration software iNodeSetup.exe works on Windows with Bluetooth adapter based on the CSR 8510 chipset or Serial USB Transceiver iNode, iNode LAN. Linux system requires iNode Serial Transceiver USB and/or iNode LAN, and e.g. Ubuntu with Wine. The current version of firmware for iNode products available on the technical support site: http://support.elsat.com.pl/ user: inode, with no password.

Application

  • Magnetic fields detection
  • Home automation
  • Alarm system
  • Care for the elderly

Specification

  • Bluetooth BLE - configurable from a PC
    • power: -18 dBm to 8 dBm (the maximum distance up to 200m in open space)
    • the name of the device
    • the threshold temperature that ignites sending the alarm
    • alarm turned on/off ignited by the movement or change of position
    • data archiving
    • a logical network to which the signals are transmitted
    • the user's password
    • the password to access the device - independent from the use of a password
  • Magnetic field sensor
    • sensitivity: max 1100µT
    • type: omnipolar (for detecting the magnetic field its direction not significant)
  • Power supply:CR2032 battery- not included
  • Plastic body
  • Size: CR2032: Ø 32mm x 9.5mm;
  • Remote replacement of the software
  • Two LED diodes
  • Motion sensor: 3 - axis accelerometer - 10 or 14-bit
  • Working temperature: from -20°C to 65°C
  • Temperature sensor resolution: 1°C
  • Humidity: 20% to 80% RGH
  • Chipset: CSR 101x
  • Weight: 5g

Voltage to 3.0 V
Voltage from 3.0 V
Voltage nominal 3.0 V
Sensor - type accelerometer
Sensor - assembly mounting mas
Smart Home Motion sensor
