Description
Platform of w 3-wheeled robot is drivenbytwo DC motorsin a form of FM90 servos with the torque of 1.5 kg*cm. The robot has threewheels covered with silicone tires,two of which have a diameter of 60 mm, one swivel 15 mm. Platform is made from redaluminium. The robot is compatible with devices likeArduinoorRaspberry Piand other minicontrollers. For platform you can useeach sensor type.
The kit consists of a chassis, four servos and four wheels for self-assembly.
Specification
- Voltage supply from 4.5 V to 6 V
- Torque: 1.5 kg*cm
- The platform is made of aluminum alloy 1.5 mm
- Color: red
- Size: 170 x 100 x 60 mm
- Weight: 147 g
The kit includes
- 2 x servo-FM90
- 2 x wheel with tires
- 1 x swivel
- platform
- set of screws
