Specification
- Sensor type PT1000
- Probe length: 50 mm
- Probe diameter: 6 mm
- Resistance at 0 °C: 1 kΩ
- Temperature range: from -30 °C to 500 °C
- Cable length: approx. 150 cm
- Connections: 3 metal braided wires
Characteristics of PT1000 sensor.
Waterproof analog high temperature sensor operating from -30 °C to 500 °C. The output is a temperature dependent resistance. The length of the probe is 50 mm.
Characteristics of PT1000 sensor.
Package width | 12 cm |
Package height | 3 cm |
Package depth | 16 cm |
Package weight | 0.04 kg |
