PowerHD HD-1900MG micro - analogue servo
The 1900MG servo from PowerHD is an advanced analog micro servo that is characterized by a solid construction and versatility. It has a power supply range from 4.8 V to 6 V , which allows for flexible adaptation to various applications.
We could not load the price.
The promotional price does not combine with quantity discounts.
Product description: PowerHD HD-1900MG micro - analog servo
The 1900MG servo from PowerHD is an advanced analog micro servo that is characterized by a solid construction and versatility. It has a power supply range from 4.8 V to 6 V , which allows for flexible adaptation to various applications. Adjusting the operating speed and torque depending on the applied voltage allows for precise movement control. The servo comes with T-bars, washers and screws , which facilitate assembly and ensure a stable connection with other elements of the system. The 1900MG servo is an irreplaceable tool in projects requiring precise motion control.
Our offer also includes cables and servo controllers .
PowerHD HD-1900MG micro - analog servo.
1900MG servo from PowerHD, standard type, powered by voltage ranging from 4.8 V to 6 V.
Technical Specifications
- Supply voltage: 4.8V to 6V
- Range of motion: 180° ±10°
- Type: analog
- Operating temperature: from -20°C to 60°C
- Operating frequency: 1520 μs / 50 Hz
- Connector: standard JR connector
- Dimensions: 23 x 12.2 x 27.5 mm
- Weight: 14 g
- Parameters for 4.8V
- Torque: 1.2 kg*cm
- Speed: 0.11 sec
- Parameters for 6V
- Torque: 1.5 kg*cm
- Speed: 0.08 sec
Useful links
| Name | Value |
|---|---|
| Voltage to | 4.8 |
| Voltage from | 6.0 V |
| Servo - Range | 180 ° |
| Servo - Size | micro |
| Servo - Type | analog |
| Width | 8 cm |
| Height | 14.4 cm |
| Depth | 1.5 cm |
| Weight | 0.019 kg |
