Product description: PowerHD HD-1900MG micro - analog servo
The 1900MG servo from PowerHD is an advanced analog micro servo that is characterized by a solid construction and versatility. It has a power supply range from 4.8 V to 6 V , which allows for flexible adaptation to various applications. Adjusting the operating speed and torque depending on the applied voltage allows for precise movement control. The servo comes with T-bars, washers and screws , which facilitate assembly and ensure a stable connection with other elements of the system. The 1900MG servo is an irreplaceable tool in projects requiring precise motion control.
Our offer also includes cables and servo controllers .
PowerHD HD-1900MG micro - analog servo.
1900MG servo from PowerHD, standard type, powered by voltage ranging from 4.8 V to 6 V.Technical Specifications
- Supply voltage: 4.8V to 6V
- Range of motion: 180° ±10°
- Type: analog
- Operating temperature: from -20°C to 60°C
- Operating frequency: 1520 μs / 50 Hz
- Connector: standard JR connector
- Dimensions: 23 x 12.2 x 27.5 mm
- Weight: 14 g
- Parameters for 4.8V
- Torque: 1.2 kg*cm
- Speed: 0.11 sec
- Parameters for 6V
- Torque: 1.5 kg*cm
- Speed: 0.08 sec
