Nvidia single-board minicomputers are a perfect combination of super-efficient multi-core processors and highly miniaturized electronics. Such a marriage is the result of many years of experience of Nvidia engineers in the field of developing chips for parallel processing of graphics and video, transferred to small printed circuit boards with an edge connector. This is how the most modern SoM (System-on-Module) modules were created, which are able to breathe the computing power of a workstation into almost any device. The offer of the Botland store includes a large range of accessories designed to work with Nvidia minicomputers and dedicated development kits from manufacturers such as Seeedstudio or Waveshare.
Products
Implementation issues of SoM modules in own projects
The use of a minicomputer in the form of an SoM module in your own device requires the design of a base board that must meet all the requirements of high-speed digital circuits. Routing USB interface paths (especially in version 3.0 and higher), HDMI or Ethernet requires in-depth knowledge of the principles of designing high-speed printed circuit boards with the rigor of signal integrity - the point is to prevent distortion of the waveforms and distortions caused by reflections in data and clock lines. Contrary to appearances, it is not enough to "pull" several paths between the connector (e.g. USB A socket) and the appropriate pins of the edge connector of the SoM module - it is necessary to use impedance control over the entire course of the paths, properly separating them from potentially interfering circuits (e.g. power supply) or finally - matching the length of individual paths with great accuracy, which is to prevent time hazards (after all, the electrical signal "moves" with a certain finite speed). The perfect solution is therefore to use ready-made base plates.
Base boards for Nvidia SoM modules
In our offer you will find several models of baseboards, containing a special socket (matching the edge connectors of Nvidia SoM modules) and a rich set of sockets and additional circuits. For example, the reComputer J101 board by Seeedstudio (compatible with the Nvidia Jetson Nano module) has an HDMI port, two USB 2.0 ports and one USB 3.0 port, as well as a microSD card slot, two CSI connectors, M.2 key E slot for WiFi+BLE modules, as well as numerous sockets providing the user with GPIO lines and low-level interfaces (including I2C and I2S). The Nvidia Jetson Nano Dev Kit board, developed by the equally popular Waveshare brand, also has a similar design. In addition to the baseboards, we also offer ready-made computers equipped with high-end housings - as an example, it is worth mentioning the reComputer J2021 model, made on the basis of the Nvidia Jetson Xavier NX module. Also check out a number of other accessories, including cameras, heatsinks, network cards, fans, extension plates and kits for building autonomous mobile robots.
