Sony IMX219-120 8Mpx camera - compatible with Jetson Nano - Waveshare 16579

Index: WSR-14785 EAN: 5904422322571

Sony IMX219-120 camera module equipped with IMX219 sensor compatible with Jetson Nano. The camera is equipped with 8 Mpx sensor. The maximum recording resolution is 3280 x 2464 px and F.O.V. field of view is 120°.

Sony IMX219-120 8Mpx camera - compatible with Jetson Nano - Waveshare 16579
€19.50
€15.85 tax excl.
Delivery 5 pcs scheduled for 2024-11-22
Waiting for delivery
PayPal payment
Manufacturer: Sony

Description: Sony IMX219-120 8Mpx camera - compatible with Jetson Nano

Sony IMX219-120 camera module equipped withIMX219 sensorcompatible withJetson Nano. The camera is equipped with8 Mpxsensor. The maximum recording resolution is3280 x 2464 px.

Kamera Sony IMX219-120 8 Mpx

Sony IMX219-120 8 Mpx camera module.

The sale includes the Sony IMX219-120 8 Mpx camera module itself,

JetsonNanomust be purchased separately.

F.O.V. field of view is 120°,aperture2.2, focal length is 1.88 . The dimensions of the whole module are 25 mm x 24 mm. The kit includes the camera, connection tape and mounting screws.

Application of the Sony IMX219-120 camera module

  • Face recognition
  • Detection of traffic signs
  • Recognition of registration plates

Technical specification of the Sony IMX219-120 camera module

Parameter Scope
Number of pixels 8 Mpx
Sensor Sony IMX219
Resolution 3280 x 2464 px
Lens specification
  • Matrix type: CMOS
  • Aperture (F): 2.2
  • Focal length: 1.88 mm
  • FOV: 120 °
  • Distortion < 13.6 %
  • Lens dimensions: 6.5 mm x 6.5 mm
Fixing 4 screw holes
Dimensions 25 mm x 24 mm
Mass 0.012 kg

Resolution 3280x2464px
Camera - matrix 8MPx IMX219
Camera - IR filter No
Package width 5.2 cm
Package height 11 cm
Package depth 2.3 cm
Package weight 0.011 kg
