Rectifier diode 1N4001 - 10pcs.
The 1N4001 rectifier diode converts alternating current to direct current, operating at a maximum voltage of 50 V and a current of up to 1 A. Due to its high temperature resistance, from -65°C to 175°C, it is used in rectifiers, power supplies and reverse polarity protection systems.
We could not load the price.
The promotional price does not combine with quantity discounts.
Product description: Rectifier diode 1N4001 - 10 pcs.
The 1N4001 rectifier diode is a semiconductor component that is commonly used in electronic circuits to convert AC to DC . It operates at a maximum voltage of 50 V and has the ability to conduct current up to 1 A. It is also resistant to high temperatures, which makes it able to operate in a wide range of conditions, from -65°C to 175°C . Typical applications for this diode include rectifiers, power supplies , and reverse polarity protection circuits.
Also check out other types of rectifier diodes available in our offer.
Rectifier diode 1N4001 - 10 pcs.
Items included in the set.
1N4001 Rectifier Diode Specification
- Type: rectifier diode
- Maximum Reverse Voltage (VRRM): 50 V
- Maximum Blocking Voltage (VDC): 50 V
- Average forward current (IF): 1 A
- Surge current (IFSM): 30 A (for a pulse duration of 8.3 ms)
- Reverse Leakage Current (IR): 5 µA @ 50 V
- Forward Voltage Drop (VF): 1.1 V at 1 A
- Capacitance: 15 pF
- Operating temperature range: -65°C to 175°C
- Housing: DO-41
Items are sold in sets of 10.
| Name | Value |
|---|---|
| Width | 6.2 cm |
| Height | 9 cm |
| Depth | 1 cm |
| Weight | 0.003 kg |
