Servo Robotis - Dynamixel AX-12A

Index: ROB-13984 EAN: 8809052930196

High precision and mechanical strength servo used in robots Robotis Bioloid. It allows you to control the position and angular velocity with a precision of 1024 steps. Supply voltage from 9 V to 12 V. Resolution of 0.29 °. Speed: 59 rpm. Dimensions: 55 x 40 x 32 mm Weight: 55 g.

Servo Robotis - Dynamixel AX-12A
€64.90
€52.76 tax excl.
Waiting time: 3-5 days
Only on request
PayPal payment
Manufacturer: Robotis

Description

Servo ofhigh accuracy and mechanical strength, used in robots Robotis Bioloid. It allows you to controlpositionandangular velocitywitha precision of 1024 steps. Servogas a built-intemperature sensor. The embedded controller gies feedback for parameters such asvoltage, temperature, speed, position and load.

Dynamixel AX-12A hastwo ports, TTL, where it is possibleto connect in series up to 254 servos. The set of structural elements makes it easy to add motors to the robots from the Bioloid kits.

Specification

  • Working voltage: 9 V to 12 V
  • Stall Torque: 1,5 Nm (at 12 V / 1,5 A)
  • Running Degree: 0° to 300° / Endless Turn
  • No-load speed: 59 RPM
  • Resolution: 0,29 °
  • Dimensions: 55 x 40 x 32 mm
  • Weight: 55 g

Set includes:

  • Servo Dynamixel AX-12A
  • 2x mounting bracket
  • Screws and nuts for mounting
  • Connecting cable
Length 55 mm
Width 40 mm
Height 32 mm
Voltage to 9.0 V
Voltage from 12.0 V
Mass 55 g
Servo - Size medium
Servo - Type digital
Package width 6 cm
Package height 5.5 cm
Package depth 5 cm
Package weight 0.09 kg
