- EOL
|
Attention! The product has been discontinued. Check others products incategory. |
Description
Resistive touchscreen 4.3" display forthe Raspberry Piwith a resolution of 480 x 272 px. Works withRaspberry Pi in versions 3, 2, B+ Zerovia the HDMI connector and the pins GPIO - necessary hardware included in the package.
The device communicates via an HDMI adapter (image) pins and GPIO (touch).
Connect to the Raspberry Pi
In order to run screen, put the device on the GPIO pins of the Raspberry Pi and connect the HDMI connector.
Example of connecting the screen tothe Raspberry Pi.
Software
The manufacturer has preparedthe operating system with the installed drivers. The system should be unpacked using a program such as WinZip and uploaded to the memory card usingWin32 Disk Imager.
Screenshot of the programWin32 Disk Imager, when you select the system, just press the Write button and wait until the installation process is completed.
|
Detailed description of the connections and driver installation, without changes to the system the Raspberry Pi and the image of the finished system can be found onthe website of the manufacturer. Drivers can be installed manually on an existing system, details can be found inthe user guide. |
GPIO
| Pin GPIO | Symbol | Description |
|---|---|---|
| 1, 17 | 3.3 V | Power 3.3 V. |
| 2, 4 | 5V | Power Supply 5 V. |
| 3, 5, 7, 8, 10, 11, 12, 13, 15, 16, 18, 24 | NC | Not connected. |
| 6, 9, 14, 20, 25 | GND | Ground. |
| 19 | TP_SPI | Input data SPI for the touch panel. |
| 21 | TP_SO | Output data SPI for the touch panel. |
| 22 | TP_IRQ | Interruption of the touch panel defining the touch establishes a low state. |
| 23 | TP_SCK | Clock signal SPI for the touch panel. |
| 26 | TP_CS | Chip select for touch panel. |
Specification
- Screen type: resistive touch
- Screen: 4,3 "
- Screen resolution: 480 x 272 px
- Works with:Raspberry Piversion 3, 2, B+ Zero
- Screen uses a 26 pin GPIO
- 4 mounting holes (screws included in the package)
- Screen dimensions: 105 x 80 mm
The outer dimensions of the screen.
Set includes
- Screen 4.3" resistive touch
- Connector HDMI
- Stylus touch pen
- Screws for mounting
