Mini PIR HC-SR505 motion sensor

Index: MOD-05862 EAN: 5904422359669

A PIR type sensor allows to detect movement. It is used to detect objects indoors in alarm and lighting systems. The sensor is powered by a voltage from 4.5 V to 15 V. Detection of an object is digitally signaled - high state.

Mini PIR HC-SR505 motion sensor
€2.15
€1.75 tax excl.
Available, 24 hours shipping!
Check quantity
Shipping in 24 hours
30-day returns
PayPal payment
Manufacturer: OEM

Product description: Mini PIR motion detector HC-SR505

PIR type sensor allows to detect motion, used to detect human presence in rooms in alarm and lighting systems. The sensor is powered by a voltage from 4.5 V to 15 V, has a range of up to 3 m. Detection of an object is indicated by a high state.

Digital output allows to connect sensor with any runtime kit e.g. Arduino, STM32Discovery or minicomputer Raspberry Pi. The outputs are goldpin connectors (raster 2.45 mm), which allow to connect the sensor with wires.

Product compatible with Arduino

How to use

Power supply (4.5V to 15V) should be connected to the external pins marked + and - on the picture below. Detection of an object, in the field of view of the sensor, is indicated by a high state appearing on the OUT pin.

Czujnik ruchu PIR HC-SR505 - wyprowadzenia

The sensor has three terminals: supply +, - and digital output out,

Specification

  • Supply voltage DC: from 4.5 V to 15 V
  • Standby current consumption: 50 μA
  • Measuring range: max. 3 m
  • Viewing angle: up to 100°
  • Delay time: 8 s -/+ 30 %
  • Digital output:
    • High state (3.3 V) - object detected
    • Low state (0 V) - no object detected
  • Dimensions of the module base: 23 x 10 mm
  • Lens diameter: 10 mm
  • Lens height: 11.5 mm

Voltage to 4.5 V
Voltage from 15.0 V
Sensor - type PIR
Sensor - assembly on wires
