DC Motor Driver HAT V1.0 - 2-channels motor driver 12V/1,2A - HAT for Raspberry Pi - DFRobot DFR0592
Two-channel DC motor controller TB6612FNG operating with voltage from 7 V to 12 V and continuous current 1.2 A per channel and momentary 2 A. The module in the form of an overlay for the Raspberry Pi communicates via the I2C interface.
We could not load the price.
The promotional price does not combine with quantity discounts.
Product description: DC Motor Driver HAT V1.0 - dual channel 12V/1.2A motor controller - cap for Raspberry Pi - DFRobot DFR0592.
Two-channelDC motorcontrollerTB6612FNGoperating with voltagefrom 7 V to 12 Vand continuous current1.2 Aper channel and momentary 2 A. The module in the form of an overlay forRaspberry Pi 4B / 3B+ / 3B / 2B / Zero / Zero Wcommunicates via theI2Cinterface.
Raspberry Pi compatible product For a sample code and detailed information, see theuser guide. |
Example of connection withRaspberry Pi.
Botland is an official distributor of DFRobot open-source hardware. Every roboticist and practitioner of emerging technology has heard at least once of DFRobot solutions, built above all around Arduino. Our range holds original DFRobot products only.
Motor controller outputs
The module is equipped with screw connectors to connect the power supply and motors together with encoders.
| No. | Pin | Description |
|---|---|---|
| 1 | + | Supply voltage from 7 V to 12 V. |
| 2 | - | GND - mass of the system. |
| 3 | E1+ | Encoder pin E1 - positive. |
| 4 | E1- | Encoder pin E1 - negative. |
| 5 | E1A | Encoder phase output pin E1 A. |
| 6 | E1B | Encoder phase output pin E1 B. |
| 7 | M1+ | M1 motor power pin - positive. |
| 8 | M1- | M1 motor power pin - negative. |
| 9 | M2- | M2 motor power pin -negative. |
| 10 | M2+ | M2 engine power pin - positive. |
| 11 | E2B | Encoder phase output pin E2 B. |
| 12 | E2A | Encoder phase output pin E2 A. |
| 13 | E2- | Encoder Pin E2 - negative. |
| 14 | E2+ | Encoder pin E2 - positive. |
Motor controller specification
- Supply voltage: 7 V to 12 V
- The voltage of the logical part: 5 V
- System: TB6612FNG
- Interface: I2C
- Default I2C address: 0x10
- Continuous current: 1,2 A
- The current of the moment: 2 A
- Number of channels: 2
- Dimensions: 65 x 30 mm
Useful links
| Name | Value |
|---|---|
| Voltage to | 7.0 V |
| Voltage from | 12.0 V |
| Current | 1.2 A |
| Channels | 2 |
| Width | 6.8 cm |
| Height | 8.1 cm |
| Depth | 2.7 cm |
| Weight | 0.028 kg |
