Product description: 2x16 I2C LCD display with backlight (White on Blue)
Monochrome 2 x 16 character LCD display withhigh brightness backlight from Grove. The module communicates with the control board via the two-row I2C bus. The screen is poweredfrom 3.3 V to 5 V.
Traditional LCD displays requireup to 10 free I/O pins onthe control board and screens with RGB backlighting require three additional pins to control the backlighting colour. This is a limitation for those who use a programming board with fewer pins such as Arduino, Raspberry Pi.With the Grove connector, only two signal pins and 2 power pins are required, just connect the module to the I2C interface inSeeeduino, RaspberryPi orArduinousingthe Grov cable.
Features and applications of the Grove module with monochrome display
- Display of 2 lines of 16 characters each
- Display mode STN (yellow green)
- Built-in MCU
- I2C interface
- Support for English and Japanese fonts
- It is used in displays for thermometers, clocks and other projects requiring simple display.
Monochrome 2X16 I2C LCD display with backlighting.
| User guide available under thislink. |
Technical specifications of Grove module with display
| Parameter | Scope |
|---|---|
| Operating voltage | 3.3 V to 5 V |
| Working temperature | From 0℃ to 50℃ |
| Storage temperature | From -10℃to 60℃ |
| Interface | I2C |
| I2C address | 0X3E |
| Dimensions | 40 mm x 80 mm x 13 mm |
| Mass | 42.9 g |
