M40180H10 lens M12 mount 1,8mm for Arducam cameras - Arducam LN006

Index: ACM-19353 EAN: 5904422358365
The lens M40180H10 is dedicated for Arducam cameras. Mounted using M12 connector, its focal length is 1.8 mm, aperture 2.4, and format is 1/4". The viewing angle when used with Raspberry Pi cameras is 100° (H). It is equipped with an IR 650 filter.
€8.78
€7.14 tax excl.
Waiting for confirmation of delivery date
Product unavailable
30-day returns
PayPal payment
Manufacturer: ArduCam

Product description: Lens M40180H10 M12 1.8mm for Arducam cameras - Arducam LN006

Lens M40180H10 is designed for Arducamcameras. It is mounted usingM12connector, has focal length of1.8 mm,aperture of 2.4, and 1/4" format. The angle of view when used with Raspberry Pi cameras is100° (H).It is equipped with IR 650 filter.

Otherlensesfor Arducam and Raspberry Pi cameras are also available in our shop's assortment.

Obiektyw ArducamArducam lens M40180H10.
Obiektyw M12Lens M12 for Arducam cameras.

Lens specification M40180H10

  • Model: M40180H10
  • Optical format: 1/4"
  • EFL (focal length): 1.8 mm
  • 35mm EFL: 19.5
  • BFL (rear focal length): 4.9mm
  • Construction: 6G + IR
  • Aperture: 2.4
  • Angle of view (FOV D/H/V) @ 1/4": 125° / 100° / 75°
  • IR Filter: 650 IR
  • Mounting: M12
  • Wavelength: 400 to 700 nm
  • MOD: 0.2 m
  • Handle height: 13 mm
  • HFOV for Raspberry Pi 1/4" cameras: 100°
  • Dimensions: 14 x 14.5 mm
  • Weight: 7 g
