Cytron HAT-MDD10 - two channel DC engine driver 24V / 10A - overlay for Raspberry Pi

Index: CTN-12413 EAN: 5904422319199

Shield with dual-channel driver of motors operating with a voltage from 6 V to 24 V and current up to 10 A per channel (max. 30). The system can be connected directly with the GPIO connectors of Raspberry Pi minicomputer 3+, 3, 2, B+ and A+.

Cytron HAT-MDD10 - two channel DC engine driver 24V / 10A - overlay for Raspberry Pi
€31.00
€25.20 tax excl.
Delivery 5 pcs scheduled for 2024-07-12
Waiting for delivery
PayPal payment
Manufacturer: Cytron
Compatibility: Raspberry Pi

Description

Shield with dual-channel driver of motors operating with a voltage from 6 V to 24 V and current up to 10 A per channel (max. 30). On board are buttons to manually control the direction of rotation of the motor. The system can be connected directly with GPIO connectors of minicomputer Raspberry Pi 3+, 3, 2, B+ and A+.

Cytron HAT-MDD10 - dwukanałowy sterownik silników

The subject of the sale is the shield with dual-channel driver of motors, minicomputerRaspberry Pican be purchased separately.

The whole system consists of the transistors NMOS H-Bridge for improved performance without the need to use the radiators.

The product is compatible with Raspberry Pi

The manufacturer has prepareda user manualand sample codefor the Raspberry Pi.

Specification

  • Supply voltage: 6 V to 24 V
  • Average current per channel: 10 A (up to 25 °C without the use of radiator)
  • Short-time current: up to 30 A (up to 10 sec)
  • Constructed of NMOS H-Bridge transistors
  • Built-in LEDs for each channel
  • Frequency of the speed control of PWM: 20 KHz
  • Buttons for manual control of motors
  • Connector compatible with: Raspberry Pi 3+, 3, 2, B+, A+
  • Supports TTL PWM from microcontroller
  • The overcurrent protection
  • Dimensions: 67,5 x 59 mm

Set includes

  • HAT-MDD10 shield
  • Extended goldpin strip of 25 mm

Voltage to 6.0 V
Voltage from 24.0 V
Current 3.5 V
Channels 2
Package width 11 cm
Package height 2 cm
Package depth 7 cm
Package weight 0.05 kg
