The Grove module is used to atomize water. It works with a voltage of 5 V. It can be used, among other things, as a humidifier, but also allows for more advanced projects where atomization is required. The set includes a cable adapted to the Seeedstudio Base Shield v2.0 cap.
|GND||The weight of the system.|
|VCC||Supply voltage 5 V.|
Arduino compatible product
The manufacturer provides auser guide for Arduino.
- Power supply voltage: 5 V
- Systems used: ETA1617, NE555
- Frequency of operation: 105 +/- 5 kHz
- Peak output voltage: 65 +/- 5V
- Maximum power: 2 W
- Dimensions: 140 x 85 x 11.6 mm
- Weight: 13 g
The set includes
- Water atomizer
- Piezoelectric diaphragm
- Grove cable
