SparkFun RedBoard Edge - compatible with Arduino
SparkFun RedBoard Edge - compatible with Arduino
SparkFun RedBoard Edge - compatible with Arduino
 - zdjęcie 1
 - zdjęcie 2
SparkFun RedBoard Edge - compatible with Arduino - zdjęcie 3
SparkFun RedBoard Edge - compatible with Arduino - zdjęcie 4
SparkFun RedBoard Edge - compatible with Arduino - zdjęcie 5

RedBoard Edge ATmega328 compatible with Arduino - SparkFun DEV-14525

Index: SPF-12372 EAN: 5904422319090
BOTLAND B. DERKACZ SPÓŁKA JAWNA Opinie z ekomi-pl.com

A module made by SparkFun, is fully compatible with the RedBoard, designed for panel mounting in an unusual case. It has 14 digital input/outputs, 6 PWM channels, 6 analog inputs, as well as popular communication interfaces. On the board is the DC connector, toggle switch, LEDs, reset button, screw connection, QWIIC and microUSB connector.

€25.88 -5%
€24.58
€19.98 tax excl.

In stock, shipping 24 hours!
(Check quantity)
Shipping in 24 hours
30-day returns
PayPal payment
Manufacturer: SparkFun

Description

A module made by SparkFun, is fully compatible with the RedBoard, designed for panel mounting in an unusual case. It has 14 digital input/outputs, 6 PWM channels, 6 analog inputs, as well as popular communication interfaces. On the board is the DC connector, toggle switch, LEDs, reset button, screw connection, QWIIC and microUSB connector.

In order to start Redboard Edge, you need to connect the system to the computer using the microUSB cable. Then, inthe Arduino IDE, choose the Arduino Uno.



Power

The module can be powered via the miniUSB cable and the external device, for example, the AC adapter, the battery or the rechargeable battery. Switching power sources is automatic. The power supply is connected to a standard DC slot. Rechargeable battery or other source should be connected to the pins of the POWER connector.

Specification

  • Supply voltage: 7 V to 15 V
  • Fully compatible withArduino Uno Rev3
  • The whole is made in SMD technology
  • Microcontroller: ATmega328
  • Maximum clock frequency: 16 MHz
  • SRAM: 2 KB
  • Flash memory: 32 KB (5kB reserved for bootloader)
  • EEPROM: 1 KB
  • I/O Ports: 14
    • Working with voltages of 5 V
    • The inputs tolerate 3.3 V voltage
  • PWM outputs: 6
  • Number of analog inputs: 6 (channels of A/C converter)
  • Serial interfaces: UART, SPI
  • MicroUSB and QWIIC connector
  • External interrupts
  • Soldered ISP connector
  • Board sizes: 101 x 38 mm

Examples of accessories

Voltage to 7.0 V
Voltage from 15.0 V
Voltage output from 5.0 V
Output voltage to 5.0 V
Nominal output voltage 5.0 V
UC - Microcontroller ATmega328
UC - Core 8-bit AVR
UC - EEPROM 1 kB
UC - Flash 32 kB
UC - RAM 2 kB
UC - core 1. Single Core
UC - Digital pins 14
UC - analog in 6
UC - freq 16 MHz
UC - A/C 10-bit
UC - PWM 6
UC - USB microUSB
UC - I2C yes
UC - UART yes
UC - SPI interface yes
