Product description: Electric actuator Super Power Jack Mini 1000N 5,4 mm/s 12V - 20 cm extension
High-speed electric actuator powered by 12 V. The device has a lifting capacity of 1000 N (100 kg), operates at a speed of 5.4 mm/s. Maximum current consumption is 1.5 A. An impulse generator with a resolution of 48 pulses/inch provides information about the current extension. Built-in limit switches, protect against exceeding the extension range. The direction is changed by reversing the polarity just like in DC motors.
The actuator is easy to install and use and can be controlled by buttons or relays. Simple adjustment of extension limit contacts makes the device successfully applicable even for beginners. After stopping operation, the gear in the form of a pull bolt will not allow to move the actuator, which is a protection against burglary.
|
The devices are available in different variants with an extension of lengths: 15 cm, 20 cm, 25 cm. |
Main features of the actuator
- High quality manufacture
- Rated voltage of 12 V DC
- Built-in pulser for precise positioning of the actuator
- Very small dimensions
- Stable operation
- Convenient articulated mounts,
- Weatherproof
- Fully adjustable extension (adjustable from a few mm to the nominal extension value)
- Versatile in use, unprecedented versatility
Application examples for Super Power Jack Mini
- Door opening
- Linear machine elements
- Widely used in agricultural machines,
- Compatible with intelligent building systems,
- Can be freely combined with equipment components
Control options
- By radio, via remote control
- Manual pushbuttons on cables
- Automation of operation based on sensors
Set contents
- Super Power Jack MINI actuator
- Articulated arm mount - bracket
- Mounting screws
- Rubber seal for the arm end
- Guarantee and instruction in Polish
Technical specification
| Name | Parameter |
|---|---|
| Supply voltage | 12 V DC |
| Current consumption | up to 1.5 A |
| Resolution of the built-in pulser | 48 pulses per inch |
| Speed | 5.4 mm/s |
| Maximum force | 1000 N (150 kg) |
| Extension length L | 200 mm |
| Total length in folded position | 200 mm + L (extension length) |
| Diameter | 25 mm |
|
Dimensions (DxSxG) |
100 x 60 x 60 mm |
