Product description: Atomic Motion Base v1.2 - power and control base for Atom series modules - M5Stack A090-V12
The Atomic Motion Base v1.2 is an advanced power and control base designed for robotic and mobile projects using Atom series controllers. Integrated STM32 and RZ7899 chips enable precise control of four servos and two DC motors , while two 4-pin connectors with a 2mm pitch allow for quick connection of environmental sensors such as temperature, humidity, and light. Power is supplied by a replaceable 18350 Li-Ion 900mAh battery , supported by a dual protection system: the DW01-A chip protects against overcharging, discharging, and short circuits, while the INA226 chip monitors voltage, current, and power in real time. With overload protection, a power switch, and a magnetically mounted design, the Atomic Motion Base v1.2 combines functionality with safety and ease of use.
Atomic Motion Base v1.2 - power and control base for Atom series modules - M5Stack A090-V12.
Atomic Motion Base v1.2 is an advanced power and control base designed for projects using Atom series controllers.Special features
- Atom Series Compatibility: Fully supports Atom, AtomS3, Atom Lite and other M5Stack controllers
- STM32 + RZ7899 controllers: reliable, low-latency drive control
- 4 servo channels: independent control of four servos with a maximum consumption of up to 0.4 A per channel
- 2 DC motor channels: Supports drives with peak currents up to 1A per channel
- Built-in 18350 battery (900 mAh): ensures mobility and energy independence
- DW01-A system: battery protection against overcharging, discharging and short circuit
- INA226 Power Monitor: Measure Voltage, Current and Power with High Precision
- 4-pin interfaces with 2 mm pitch: quick connection of sensors and expansion modules
- Independent power switch: convenient control of system operation
- Programming in UiFlow 1/2 and Arduino IDE
Applications
Atomic Motion Base v1.2 is ideal for projects such as controlling DC vehicles, robotic arms, mobile manipulators, and remotely controlled research platforms. Its compact design and support for frameworks such as UiFlow and Arduino make it an excellent choice for both hobbyists and professionals.
Safe and intelligent power supply for mobile devices
Atomic Motion Base v1.2 is not only a drive controller but also an intelligent power source for your project. Thanks to two independent protection circuits (DW01-A and INA226), the device provides complete control over battery health and system safety. Features such as output overload protection and precise current monitoring make it an excellent solution for projects requiring reliability.
Multi-channel drive control in a compact form
The compact form of the Atomic Motion Base v1.2 conceals powerful control capabilities. Independent channels for servos and DC motors allow you to build advanced robotic arms, vehicles, or mobile platforms with multiple degrees of freedom. Thanks to two 4-pin connectors with a 2 mm pitch, you can easily expand your project with additional sensors and functions without the need for hardware modifications.
Integrated STM32 and RZ7899 systems enable precise control of 4 servos and 2 DC motors.
Atomic Motion Base v1.2 combines functionality with safety and comfort of use.Atomic Motion Base v1.2 Technical Specifications
- Microcontroller: STM32F030F4P6
- DC motor driver: RZ7899
- Voltage/current monitoring system: INA226
- Charging system: ETA9740
- Battery protection system: DW01-A
- Cut-off voltages: charge 4.14V / discharge 2.5V
- Overload protection: 5V, 5A
- Battery: Li-Ion 18350, 900 mAh (replaceable)
- Motor pin spacing: 2.54 mm
- Servo full load current: 3 A
- Peak DC motor current: 1 A/channel
- Peak Servo Current: 0.4 A/channel
- Quiescent current: 4.04V, 40.97µA
- Charging current: 5V, 1.18A
- Operating temperature: 0°C to 40°C
- Dimensions: 75.4 x 24 x 20.7 mm
- Weight: 41 g (with battery)
Contents of the set
- 1 x Atomic Motion Base v1.2
- 1 x 18350 Li-Ion Battery (900 mAh)
