M5Stack CoreS3 SE developer module - ESP32-S3 - M5Stack K128-SE

Index: MSS-25332 EAN: 6972934175304

M5Stack CoreS3 SE is a simplified version of the ESP32-S3 based IoT controller, equipped with a dual-core Xtensa LX7 processor at 240 MHz and 16 MB of Flash and 8 MB of PSRAM. It has a 2-inch IPS capacitive touchscreen , a built-in 1 W speaker, a microphone and a microSD slot. It supports WiFi (2.4 GHz), OTG and CDC. Thanks to low-voltage power management, it is an ideal solution for IoT, Smart Home and industrial automation projects.

M5Stack CoreS3 SE developer module - ESP32-S3 - M5Stack K128-SE
€48.50
€39.43 tax excl.
Available
Shipping in 24 hours
PayPal payment
Manufacturer: M5Stack
Compatibility: M5Stack Core

Product description: M5Stack CoreS3 SE - development module - ESP32-S3 - M5Stack K128-SE

M5CoreS3 SE is a slimmed down version of the third generation CoreS3 main unit in the M5Stack development kit series. The module is based on the ESP32-S3 chip, supports WiFi wireless communication and offers high performance. Equipped with a dual-core Xtensa LX7 processor at 240 MHz , 16 MB Flash and 8 MB PSRAM, it allows easy support for IoT applications. The device has a built-in 2'' IPS touch screen , a microphone and a 1 W speaker. Thanks to the OTG and CDC interfaces, it is possible to connect USB devices and program via the USB Type-C port. It also has power management functions , which ensures long-term operation with minimal power consumption. Ideal for creating home automation solutions, IoT control systems and DIY projects.

The manufacturer has prepared a detailed user guide that makes it much easier to start working with the module.

M5Stack CoreS3 SE - Development Module - ESP32-S3 - M5Stack K128-SE

M5Stack CoreS3 SE - development module - ESP32-S3 - M5Stack K128-SE.

M5Stack CoreS3 SE - Development Module - ESP32-S3 - M5Stack K128-SE

M5CoreS3 SE with built-in ESP32-S3.

Main features of the module

  • Processor : ESP32-S3, Dual-Core Xtensa LX7, 240 MHz
  • Memory : 16MB Flash, 8MB PSRAM
  • Screen : 2" capacitive touch IPS, 320 x 240 px
  • Connectivity : WiFi (2.4 GHz), USB Type-C port with OTG and CDC function
  • Power Supply : AXP2101 with power management, low power consumption
  • Sound : Built-in 1W speaker, microphone and ES7210 audio decoder
  • Expansion : microSD slot, support for Arduino and UIFlow platforms

M5Stack CoreS3 SE Applications

M5Stack CoreS3 SE is perfect for IoT applications, Smart Home systems, industrial automation, as well as various DIY projects. Thanks to its versatility and low energy requirements, the module is ideal for creating mobile solutions, real-time monitoring and control . It can be successfully used in prototyping and education in programming and electronics.

M5Stack CoreS3 SE - Development Module - ESP32-S3 - M5Stack K128-SE

The module has the USB C and Grove connectors known from previous generations, as well as a microSD card slot.

Comparison of M5CoreS3 and M5CoreS3 SE
Model M5CoreS3 M5CoreS3 SE
Camera (GC0308) ×
Proximity sensor (LTR-553ALS-WA) ×
IMU (BMI270) ×
Magnetic compass (BMM150) ×
RTC
Microphone
Loudspeaker
PMIC (AXP2101)
16MB FLASH and 8MB PSRAM
Touch screen
M5Stack CoreS3 SE - Development Module - ESP32-S3 - M5Stack K128-SE

M5Stack CoreS3 SE - IoT controller without bottom module with battery.

M5Stack CoreS3 SE Technical Specifications

  • Processor: ESP32-S3 Xtensa LX7, 240 MHz
  • Memory: 16MB FLASH, 8MB PSRAM
  • Screen: 2" IPS, 320 x 240 px
  • Connectivity: WiFi 2.4 GHz, USB Type-C (OTG, CDC)
  • Power Management: AXP2101, Low Power Consumption
  • Sound: 1W speaker, microphone, ES7210 audio decoder
  • Slots: microSD, Grove
  • RTC: BM8563
  • Power supply: 5V DC USB / 4.2V DC lithium battery (max. 940mA)
  • Operating temperature: 0°C to 40°C
  • Dimensions: 54 x 54 x 15.5 mm
  • Weight: 38.4 g

Kit Contents

  • 1x M5CoreS3SE

UC - Microcontroller ESP32-S3
UC - Core Tensilica Xtensa LX7
UC - Flash 16 MB
UC - RAM 8 MB
UC - freq 240 MHz
UC - WiFi yes
UC - microSD yes
UC - I2C yes
UC - UART yes
UC - Connector USB typ C
UC - SPI interface yes
Package width 9.5 cm
Package height 13.5 cm
Package depth 2.3 cm
Package weight 0.054 kg
