TB6612FNG - two-channel motor controller

Index: UCC-00495 EAN: 5904422365172

Two-channel H-bridge. Continuous current per channel 1,2 A momentary up to 3,2 A. Supply voltage up to 15 V. Housing SSOP-24 (SMD).

TB6612FNG - two-channel motor controller
€2.16
€1.76 tax excl.
Expected availability date: January 2022
Product unavailable
30-day returns
PayPal payment
Manufacturer: OEM

Product description: TB6612FNG - 2-channel motor controller

Two channel H-bridge. Continuous current per channel 1,2 A momentary up to 3,2 A. Supply voltage up to 15 V. Housing SSOP-24 (SMD).

Controller's specification

  • Maximum supply voltage for motors: from 4.5 to 15 V
  • Continuous current 1,2 A
  • Instantaneous current: 3,2 A
  • Low current mode (Standby)
  • Possibility of changing the direction of rotation of the motor
  • Quick stop of the motor
  • Housing: SMD SSOP24
  • Controller channels can be combined to obtain higher current capacity
Sterownik silnika TB6612FNG

We also offer a module with TB6612 driver. The chip has holes for goldpin connectors (2.54 mm pitch), which allow to plug it into contact board or connect it by wires.

Pinouts of TB6612FNG chip.

PIN DESCRIPTION
VCC 4.5 to 15V motor supply - filtered with 22uF (C30) and 100nF (C22) capacitors
VDD Logic part supply 2.7V to 5.5V - filtered with 10uF (C25) and 100nF (C24) capacitors
A_PWM Channel A PWM input
B_PWM PWM input of channel B

A_IN2

A_IN1

Input specifying the direction of rotation of channel A

B_IN2

B_IN1

Input specifying the direction of rotation of channel B

MA_OUT1

MA_OUT2

Motor outputs of channel A

MB_OUT1

MB_OUT2

Channel B motor outputs
MGND Separate ground potential path for the motor power supply (ground connected in one point)
GND Separate ground potential path for the logic part (ground connected in one point

Wiring diagram of a bridge with two DC motors.

Wiring diagram of a bridge with one DC motor. Combined channels. Increased current capacity.

PIN DESCRIPTION
VCC 4,5 to 15V motor supply - filtered with 22uF (C30) and 100nF (C22) capacitors
VDD Logic part supply 2,7V to 5,5V - filtered with 10uF (C25) and 100nF (C24) capacitors
PWM Connected PWM inputs of channel A and B

IN2

IN1

Connected inputs determining direction of rotation of channel A and B

M_OUT1

M_OUT2

Motor outputs of channel A and B connected
MGND Separate ground potential path for the motor power supply (ground connected in one point)
GND Separate ground potential path for the logic part (ground connected in one point

Video describing the operation of the H-bridge - DC motor driver.

Voltage to 4.5 V
Voltage from 15.0 V
Current 1.2 A
Channels 2
