Product description: Pinecil V2 - Smart portable mini soldering iron - OLED - RISC-V - Pine64
Pinecil V2 is a smart, portable soldering iron with a 32-bit RISC-V chip that heats up to operating temperature in just 6 seconds. It features a sleek and slim design, with a SAE 304 stainless steel tip surrounded by a polycarbonate housing. This makes it not only durable , but also lightweight and comfortable to use. A temperature control range of 100°C to 400°C allows you to adapt to different tasks, and the clear OLED display makes it easy to monitor settings. The automatic standby function increases safety by turning the device off when not in use.
Pinecil V2 - Smart Portable Mini Soldering Iron - Pine64.
Pinecil V2 is an intelligent, portable soldering iron with a 32-bit RISC-V chip that heats up to operating temperature in just 6 seconds.Special features of the soldering iron
- Fast heat-up : Reaches operating temperature in 6 seconds for increased work efficiency.
- Temperature control : Temperature can be set from 100°C to 400°C to suit your different needs.
- Dual Power Source : Supports USB-C Power Delivery (PD & QC 3.0) and DC 5.5/2.5mm jack, providing flexibility in choosing the power source.
- Compact design : Lightweight and slim design makes it easy to carry and store.
- Auto Standby Mode : Saves energy and increases safety by turning off the device when not in use.
- OLED display : The clear screen allows you to easily monitor temperature settings and device status.
Technical specification
- Processor: 32-bit RV32IMAFC RISC-V
- Internal memory: 192 KB Flash
- System memory: 132 KB SRAM
- Display: OLED monochrome, 0.69'', 96 x 16 px
- Software: open source with firmware upgrade option (IronOS)
- Temperature range: 100°C to 400°C
- Heating speed: about 6 seconds to 300°C
- Power: USB C or DC 5.5/2.5mm jack
- Safety: automatic inactivity detection and overheating protection
- Dimensions: 155 x 12.8 x 16.2 mm
- Weight: 28 g with tip
Kit Contents
- Pinecil V2 Soldering Iron
- ST-B2 soldering tip (short)
The automatic standby feature increases safety by turning off the device when not in use. Useful links |
