Product description: Zamel Supla ROW-07 - 7x 230 V WiFi relay - Android / iOS application
The ROW-07 controller from Zamel Supla is a surface-mounted WiFi receiver that allows independent control of up to seven channels – both manually and remotely via a mobile app . The device is designed to control lighting and other electrical devices powered by 230 V AC . Cloud-based schedules allow users to program devices to automatically turn on and off at specific times. The receiver also provides information on the current status of outputs , enhancing control and user safety.
The ROW-07 controller from Zamel Supla is a surface-mounted WiFi receiver that allows independent control of up to seven channels.
Special features
- Seven independent channels: can control seven different electrical circuits
- Remote control via WiFi: operation via the Supla app from anywhere in the world
- Scheduling support: automate device operations with cloud-based scheduling
- Output status information: the user knows whether the devices are on or off
- Surface mounting: quick and easy installation without the need to interfere with the flush-mounted installation
- High compatibility: works with incandescent, halogen, CFL and LED lighting
Practical applications
The ROW-07 receiver is ideal for residential and commercial buildings requiring remote or automatic management of multiple circuits. It allows control of garden lighting, interior lighting, ventilation, and other electrical devices. Thanks to its scheduling capabilities, it is also suitable for home automation systems, improving comfort and energy efficiency.
Technical specifications of the relay
- Power supply voltage: 230 V AC
- Frequency: 50/60 Hz
- Power consumption: 3.2 W
- Transmission: WiFi 2.4 GHz (802.11 b/g/n)
- Transmitting power: ERP < 20 mW
- Number of output channels: 7
- Relay type: 7 x NO (voltage normally open contact)
- Relay load capacity: 5 A / 250 V AC
- Maximum load:
- Incandescent/Halogen bulbs: 750 W
- CFL: 250 W
- LED lighting: 60 W
- Number of terminals: 10 (for wires up to 2.5 mm²)
- Operating temperature: -10°C to 55°C
- Degree of protection: IP20
- Mounting: surface-mounted
- Dimensions: 167 x 52.5 x 38, 5 mm
- Weight 177 g
The receiver also provides information about the current status of the outputs, which increases control and safety of use.
