Rocker switch, triple, type of On-Off with backlight. It is equipped with the 9 contacts with the load capacity of 250 V / 16 A. Pins pitch is 11 mm. The size of the switch is 40 x 36,2 x 22.6 mm.
Rocker switch, triple, type of On-Off with backlight for alternating current. It is equipped with the 9 contacts with the load capacity of 250 V / 16 A. Pins pitch is 11 mm. The size of the switch is 40 x 36,2 x 22.6 mm.
| Switch - type2 | bistable |
| Switch - type | rocker switch |
| Switch - shape | rectangular |
| Switch - backlight | yes |
| Colour | red |
| Length | 40 mm |
| Width | 36.2 mm |
| Height | 22.6 mm |
| Package width | 7 cm |
| Package height | 10 cm |
| Package depth | 3.32 cm |
| Package weight | 0.025 kg |
| Piotr
04/17/23 | Question: The switch contacts are NC and NO in the same state or is the 3rd contact for illuminating the switch? |
Answer: The 3rd pin of the switch is used to power the backlight diode. | |
