Product description: Tuya - relay with energy meter - 50 A - ZigBee - Android / iOS application - RTX ZCR1-50EM
The RTX smart relay is an advanced device designed for smart homes . It enables remote control of electrical circuits using the Tuya Smart app. The device operates based on the ZigBee standard, requiring a ZigBee gateway that connects system components to a server. The relay monitors current energy consumption and archives data, presenting it in easy-to-read graphs. Manual control functions using the ON/OFF button and the ability to set automation scenarios based on voltage, current, or power measurements allow for complete control over energy consumption. Compatible with Google Home and Amazon Alexa , the relay enables voice control. Easy DIN rail mounting and a built-in antenna ensure stable and trouble-free communication.
Attention!
To work properly, the device requires connection to a ZigBee gateway , which must be purchased separately.
Tuya - relay with energy meter - 50 A - ZigBee - Android / iOS application - RTX ZCR1-50EM.
The relay enables remote control of the power circuit and monitors current energy consumption.
Special features of the relay
- Remote control from any location in the world.
- Manual control with the ON/OFF button.
- Possibility to set scenarios depending on voltage, current or power measurement.
- Set initial energy limit.
- Configuring schedules.
- Works with Google Home and Amazon Alexa.
- Easy mounting on a DIN rail.
- ZigBee communication (requires ZigBee gateway).
- Archiving of energy consumption data (daily, monthly, annually).
- Mesh topology for stable communication.
- Low power consumption.
Tuya Smart app support
The Tuya Smart Life app offers easy installation and hassle-free operation, allowing you to remotely control devices and monitor energy consumption. Integration with over 11,000 different devices allows you to expand your smart home system.
ZigBee 3.0 technology was created for use in IoT systems and smart homes.
ZigBee connectivity
ZigBee is an open radio communications standard supported by leading consumer electronics manufacturers. Version 3.0 is optimized for IoT and smart home systems, providing fast, stable, and secure operation with low power consumption.
Remotely turning on and off electrical circuits
Using the Tuya Smart app, you can remotely turn electrical circuits in your home on or off by setting schedules and automation scenarios . The ability to configure devices to automatically turn on or off based on time of day, randomly, or according to other user preferences ensures convenience and safety.
Current energy consumption data
The relay allows you to monitor current current draw (I), current power consumption (P), current supply voltage (V), and current energy consumption (kWh). This data is archived and presented in easy-to-read graphs , facilitating energy consumption monitoring and analysis.
The device has a function of archiving energy measurements.
The relay can be easily mounted on a DIN rail.
Technical specifications of the RTX ZCR1-50EM relay
- Type: ZigBee relay with energy consumption meter
- Model: ZCR1-50EM
- Supply voltage: 85 V to 265 V AC, 50/60 Hz
- Maximum current: 50 A
- Control range: unlimited (works with mobile internet)
- ZigBee protocol: version 3.0 according to the standard: 802.15.4
- Antenna type: built-in
- Status indicator: LED
- Application: iOS / Android (ZigBee control unit required for operation)
- Compatibility with systems: Amazon Alexa, Google Assistant
- DIN rail mounting
- Operating temperature: 0°C to 50°C
- Dimensions: 100 x 73 x 18 mm
