Product description: Sonoff SPM-Main - central unit of energy monitoring system - Ethernet / WiFi - Android / iOS application
The Sonoff SPM system is an advanced solution for monitoring and managing energy consumption in various environments, such as offices, shopping malls, and server rooms. The SPM-Main central unit communicates with the cloud via Ethernet or Wi-Fi , and with SPM-4Relay modules via RS-485, ensuring stable data transmission over long distances. The system allows you to connect up to 32 SPM-4Relay modules to one SPM-Main unit, which gives you the ability to monitor up to 128 channels simultaneously. Additionally, thanks to the SD card slot (supported cards with a capacity of 8 GB to 32 GB , SDHC), it is possible to locally store energy consumption data from the last 180 days, with access via the HTTP API interface. The controller is designed for easy integration with electrical systems - DIN rail mounting allows for quick and convenient implementation in existing infrastructure.
Sonoff SPM-Main - central unit of the energy monitoring system - Ethernet / WiFi - Android / iOS application.
The Sonoff SPM system is an advanced solution for monitoring and managing energy consumption in environments such as offices or server rooms.Special features of the controller
- Stable data transmission - communication with relay modules via RS-485 enables reliable operation over long distances
- Remote management - Ethernet and WiFi support allows convenient system control via the eWeLink application
- Local data storage - thanks to the built-in SD card slot (from 8 GB to 32 GB) you can store energy consumption data for up to 180 days
- Support for multiple modules - the ability to connect up to 32 SPM-4Relay modules allows you to monitor up to 128 channels simultaneously
eWeLink App
Sonoff SPM-Main can be easily integrated with the eWeLink app, which acts as a comprehensive management center for the device. After a quick and intuitive setup process, the user gains full control over the energy monitoring system directly from their smartphone. The app allows remote monitoring of energy consumption in real time, turning on and off circuits connected to SPM-4Relay modules, and viewing recorded historical data. With the ability to create work schedules and automation scenarios, the user can customize the system to their needs.
The SPM-Main central unit communicates with the cloud via Ethernet or WiFi, and with the SPM-4Relay modules via the RS-485 interface.
The controller is designed for easy integration with electrical systems - DIN rail mounting allows for quick and convenient implementation in existing infrastructure.Sonoff SPM-Main Technical Specification
- Communication with modules: RS-485
- Power supply: 100V to 240V AC
- Network support: Ethernet, WiFi
- SD card slot: Supports SDHC cards from 8GB to 32GB
- Maximum number of modules: up to 32 SPM-4Relay modules (128 channels)
- Application: eWeLink
- Data storage: up to 180 days on SD card
- Mounting: DIN rail
- Dimensions: 142.5 x 90 x 66.5 mm
