Product description: Sonoff TH Elite - WiFi relay with humidity and temperature measurement function - 16 A - white
TH Elite is a smart switch from Sonoff that not only allows you to monitor temperature and humidity, but also gives you the ability to automatically control devices based on these parameters. The ESP32 microcontroller ensures stable operation, and the LCD display allows you to conveniently view real-time data. It allows you to set temperature and humidity thresholds and automate the operation of devices such as heating, cooling or irrigation systems. The switch supports a maximum load of up to 16 A , making it an ideal choice for controlling high-power devices. Thanks to the dry contact output function, users can control systems that only require a closed circuit, without the need to provide power, such as gates, locks or traditional thermostats. Integration with voice assistants such as Alexa or Google Assistant allows for convenient voice control, and support for the Home Assistant platform makes the device easily fit into existing smart home systems. The ability to export data to an .xlsx file and browse the measurement history from the last 6 months gives the user even greater control over the operation of devices.
The switch does not include a temperature and humidity probe.
Sonoff TH Elite - WiFi relay with humidity and temperature measurement function - 16 A - white.
TH Elite is a smart switch from Sonoff that allows you to monitor temperature and humidity.Special features of the switch
- Maximum load 20 A : supports high power consumption devices such as electric floor heating
- Dry contact output : allows control of circuits without powering them, ideal for controlling boilers or other systems controlled by a traditional switch
- Support for various sensors: compatible with THS01 temperature and humidity sensors, DS18B20 waterproof temperature sensor, and MS01 soil moisture sensor
- Data history : ability to view historical data from the last 6 months with hourly accuracy and export in .xlsx format
- Real-time notifications: push notifications arrive on your phone when temperature or humidity values reach set thresholds or when the device status changes
- eWeLink and Home Assistant integration: control and automation via the eWeLink app and integration with Home Assistant via the eWeLink plugin
- Voice Control: Compatible with Amazon Alexa and Google Assistant, allowing you to control it using voice commands
eWeLink App
Sonoff TH Elite can be easily connected to the eWeLink app, which is the device's management center. After a quick setup process, users gain full control over the switch via their smartphone. The app allows you to remotely turn on or off connected devices, monitor real-time energy consumption, and view historical data. What's more, eWeLink allows you to set work schedules, create automation scenarios, and receive notifications when energy consumption exceeds set limits. This allows users to effectively manage their energy consumption no matter where they are, with the only requirement being internet access.
The switch supports a maximum load of up to 16A, making it an ideal choice for controlling high-power devices.
It offers the ability to export data to an .xlsx file and view the measurement history for the last 6 months.Switch Technical Specifications
- Model: THR316D
- Microcontroller: ESP32
- Display: LCD
- Input/Output Voltage: 100V to 240V ~ 50/60Hz
- Maximum load: 16 A
- Housing material: PC V0 (fireproof)
- Potential-free output (dry contact): yes
- Sensor Interface: RJ9 4P4C
- Compatible sensors: THS01, DS18B20, MS01
- Voice control: Amazon Alexa, Google Assistant
- Integration: eWeLink App, Home Assistant
- Data history: Readings from the last 6 months, export in .xlsx format
- Dimensions: 98 x 54 mm
