Product description: Mounted power supply POS-50-12-C2 - 12 V / 4,2 A / 50,4 W
The 50.4 W fixed voltagemounting power supplyhas a universal range of input voltage values. The output voltage is 12 Vand the output current is 4.2 A. The power supply has a number of protections. Over-voltage protection cuts off the output voltage and automatically restores normal operation after the cause has ceased. Short-circuit protection alternately switches on / off the output voltage. Overload protection alternately switches on/off the output voltage and automatically returns to normal operation after the cause of the fault has ceased. The outputs of the power supply have a form of a terminal strip.
The POS-50-12-C2 mounting power supply features overload, short circuit, and over voltage protection.
Power supply specification
- Supply voltage: 100-240 VAC / 1,0 A
- Type: direct voltage
- Output voltage: 12 V DC
- Output current: 4,2 A
- Power: 50,4 W
- Connections in the form of a terminal strip
- Protection: overload, short-circuit, overvoltage
- Work temperature: from -30°C to 70°C
- Dimensions: 99 x 82 x 30 mm
- Weight: 200 g
