Linear Actuator CAR+ 1000N 10mm/s 12V - 20cm stroke
A linear electric actuator specially designed for 12 V installations. The maximum current consumption is 3 A. The device works at a speed of approx. 10 mm/s (no load), its maximum load capacity is 100 kg (1000 N). The extension value is 20 cm, it can be regulated by means of limit switches. The housing of the actuator is entirely made of metal. The product protection class is IP53. The CAR+ series models are equipped with rear mounting brackets.
We could not load the price.
The promotional price does not combine with quantity discounts.
Botland is an official distributor of Elektrobim products. Elektrobim is a Polish company that designs, manufactures and distributes electric drives, linear actuators and industrial automation components. Elektrobim products are known for their build quality and reliability, which earns them the trust of customers across many industries. Botland carries a wide range of original Elektrobim products supporting advanced automation systems.
Product description: Electric actuator CAR+ 1000 N 10 mm/s 12 V - 20 cm extension
Linear electric actu ator designed for 12 V systems. The maximum current consumption is 3 A. The actuator operates at a speed of approx. 10 mm/s (no load), its maximum load capacity is 100 kg (1000 N). The extension value is 20 cm, it can be regulated by means of limit switches. The housing of the actuator is entirely made of metal. The product protection class is IP53. The CAR+ series models are fitted with rear mounting brackets.
Electric actuator CAR+ 1000 N 10 mm/s 12 V - 20 cm extension.
Linear actuator CAR+ - 20 cm extension.
Advantages of the CAR+ actuator
- Robust manufacture using high quality materials
- Stable operation for high extension precision
- A mounting bracket at the back of the housing facilitates correct installation of the actuator
- Designed for use in 12 V systems
- Protection class IP53 ensures resistance to weather conditions
- Extension can be adjusted (from several mm to nominal value) using limit switches
Examples of actuator applications
- Agriculture - moving elements of ploughs, orchard platforms, sprayers, henhouse doors
- Home automation - DIY projects, lifting elements of: desks, tables, beds, flaps, tilt windows
- Vehicles - opening the trunk lid, gas control
- Industry - use as an executive element in various production lines
Specification of a CAR+ linear actuator
Technical specification
| Supply voltage | 12 V |
|---|---|
| Maximum current | 3 A |
| Load capacity | 1000 N (100 kg) |
| Extension | 20 cm |
| Pull-out speed (no load) | approx. 10 mm/sec. |
| Protection class | IP53 |
| Protections | limit switches |
| Duty cycle | 20% (max. 2 min. continuous operation) |
| Working temperature | from -25°C to 45°C |
| Name | Value |
|---|---|
| Torque | 100 kg*cm |
| Voltage nominal | 12 V |
| Motor - linear speed | 10 mm/s |
| Motor - eject | 20 cm |
| Width | 44 cm |
| Height | 4.5 cm |
| Depth | 7.5 cm |
| Weight | 1.02 kg |
