Description: 18650 Battery Charger - XTAR MC1+
Fast, universal charger with LCD display XTAR MC2. It has 1 independent charging channel. The device supports the following battery sizes:
- 10440
- 14500
- 14650
- 16340
- 17500
- 17670
- 18350
- 18500
- 18650
- 18700
- 22650
- 25500
- 26650
The charger automatically and independently selects the charging current for each channel: 500 or 1000 mA depending on the power source. It has a 3-stage TC / CC / CV charging process and a deep-discharged battery reactivation function.
The object of sale is the charger. The batteries can be purchased separately.
Charger specifications
- Input voltage: 5 V DC, 1 A from microUSB port (microUSB-USB cable included)
- Charger designed to charge Li-ion batteries
- LED screen indicates the progress and charging current of the battery
- Maximum battery length: 70 mm
- Charging method: processor-controlled TC / CC / CV
- Charging current :
- Battery length < 54 mm 500 mA ± 50 mA
- batteries > 54 mm in length: 1000 mA ± 80 mA
- Built-in protection:
- Short-circuit
- Thermal
- Against reverse polarity of cells
- Device dimensions: 92 x 25 x 26 mm
- Weight: 26 g
18650 battery charger - XTAR MC1+
We offer a device for charging rechargeable batteries of various sizes - it is a charger for 18650, 10440, 14500, 14650, 16340, 17500, 17670, 18350, 18500, 18700, 22650, 25500, 26650 cells. The device has a system based on the work of a spring, so that the length of the bearing on the battery changes as needed.
The charger also has a system of automatic selection of charging parameters depending on the state of the battery inside. Depending on the connected power source, a current of 500 mA or 1000 mA is activated.
Charger for 18650 batteries
The equipment can recognize a deeply discharged battery and, if necessary, activates the reactivation function of such cells. The charger also uses a three-stage charging process to ensure that the batteries last as long as possible.
The device is equipped with protection against mistakenly placed batteries in reverse polarity, it also has short circuit and overheat protection. In addition to the charger itself, you'll get a dedicated USB-micro-USB cable and a carrying case for it all.
