Product description: Set of electric cubes 2 / 3 / 4 / 5 pin 32 A / 250 V - orange - 46 pcs - justPi
The set consists of 46 pieces of justPi electrical cubes with different numbers of pins. The cubes allow you to connect wires with a voltage of up to 250 V with a current flow of up to 32 A in an easy way, without the need for tools. The elements of the set are packed in a transparent organizer, which makes it easy to store. The price includes the entire package.
Also check out other offers of electric cubes and justPi products available in our store.
Set of electrical cubes 2 / 3 / 4 / 5 pin 32 A / 250 V - orange - 46 pcs. - justPi.
Electrical cube 3 pin 32 A / 250 V.
What is an electrical connector (cube)
An electrical insulating product designed to connect the current path of two sections of low-voltage power cables. This connection is made using clamps or other connecting elements placed at the ends of the path. These paths are placed on an insulating base or in an insulating housing.
Main features of electrical connectors
- They can be used in AC installations up to 32 A.
- They provide a mechanical connection between the cables.
- They allow you to quickly connect wires together
- They are designed for all types of wires: from 0.75 mm 2 to 2.5 mm 2
Specifications of the justPi electric cube set
- Electric cubes with number of sockets:
- 2 (PCT-212)
- 3 (PCT-213)
- 4 (PCT-214)
- 5 (PCT-215)
- Current: up to 32 A
- Voltage: up to 250 V / 4 kV
- Wire cross-section: 0.08 to 2.5 (4.0) mm 2
- Cube dimensions:
- PCT-212: 20 x 14 x 12 mm
- PCT-213: 20 x 14 x 17 mm
- PCT-214: 20x14x22mm
- PCT-215: 20 x 14 x 26mm
Kit Contents
Electric cubes with number of sockets:
- 2 (PCT-212) - 16 pieces
- 3 (PCT-213) - 16 pieces
- 4 (PCT-214) - 4 pieces
- 5 (PCT-215) - 10 pieces
Contents of a dice set.
