Product description: Laser diode 1mW red 650nm 5V - Velleman WPM434
Module with a red laser diode with a power of 2 W and a beam length of 650 nm . It is powered by 5 V. It consumes up to 400 mA of current.
Specification of the laser diode module
- Supply voltage: 5V
- Wavelength: 650 nm
- Power: 2W
- Current consumption: 400 mA
- Operating temperature: from -10°C to 40°C
- Dimensions: 18.5 x 15 mm
2W red laser diode.
Module pins.
Connecting the module
The module works with any microcontroller. It has 3 pins, including one inactive. Just connect the 5V power supply and ground, and the module will start emitting light.
Attention! Do not look directly into the laser light source with your naked eye, as this may damage your eyesight. |
