Description
Minicomputer ROCKPro64 with a powerfulprocessor RK3399 RockChip Dual-Core Cortex-A72 2.0 GHz + Quad-Core Cortex-A53 1.5 GHz. The board has a 4 GB DDR4 RAM, Gigabit Ethernet port, HDMI (4K), 2 x USB 2.0, USB 3.0 type C, 2 x 20 GPIO connector for memory cards microSD, mini-Jack 3.5 mm connector, 4 x PCI-e, CSI, eDP, and DSI. It works with, in particular, systems Debian, Ubuntu, and Android. The device is compatible with Raspberry Pi extensions.
The device has 2 x USB 2.0, 1 x USB 3.0 type C, connector HDMI, Ethernet port and many others.
How do you start the minicomputer ROCKPro64?
- The microSD card has an operating system installed on it
- Power supply:
- 12 V / 3 A for the minicomputer
- HDMI cable - to connect the device to the monitor
- Mouse and keyboard - for control and data input into the device
- Connected Internet - to download the software
Operating system
ROCKPro64 works with multiple systems, in particular with Debian, Ubuntu, and Android. The disk of the device is the the microSD card or eMMC.
|
The installation is very simple - check the user manual! |
Communication
ROCKPro64 has communication interfaces that can be found in office PCs. The user has at their disposal:
- two USB 2.0 ports, which can connect, for example, a mouse, a keyboard, a wi-fi card or USB flash drive. If you find that the slots are too short, you can increase their number using an external USB HUB.
- Ethernet connector, that is the ability to directly connect to the network.
- GPIO x 40 pins, gpios that can be used to control the LEDs, buttons, drivers, engines. Among them there are pins that supports interfaces: I2C, SPI and UART. Compatible with extensions for Raspberry
- microSD slot for memory cards microSD, which can have an operating system installed.
ROCKPro64 has a connector for memory cards microSD. Card is not included, it can be purchased separately.
Power supply
As a power source, the system uses a DC connector 5,5 / 2,1 mm. Manufacturer recommends that the voltage indicated on the plug has a value of 12V, a maximum output current of the used adapter needs to be at least 3.0 A or 5 A. In our offer you will find a dedicated power supply.
|
Attention! If you connect more devices to the board, (such as: hard disk, PCI-e) the minicomputer needs more power, in this case the manufacturer recommends to use a power supply 5 A. |
ROCKPro64has a HDMI port through which you can sens bot image and sound in 4K.
Specifications and comparison
| Basic information | ||
| Model | Raspberry Pi 3 model B+ | ROCKPro64 |
| Edition | 3 - by 2018. | 2018. |
| Technical specification | ||
| Core | Quad-Core ARM Cortex A53 |
Quad-Core ARM Cortex-A54 Dual-Core ARM Cortex-A72 |
| Operating systems |
Linux Raspbian Windows 10 flight |
Debian Ubuntu Android, etc. |
| Clock frequency | 1.4 GHz | 1.5 GHz + 2.0 GHz |
| RAM | 1 GB LPDDR2 @ 900 MHz | 4GB DDR4 |
| Memory | microSD memory card |
microSD memory card eMMC |
| Connector GPIO |
Connector 40-pin (2x20 pin) raster 2.54 mm |
Connector 40-pin (2x20 pin) raster 2.54 mm |
| Power supply |
A 5.1 V / 2.5 A via microUSB |
12 V / 3 A / 5 A DC 5.5 / 2.1 mm |
| Board sizes | 85 x 56 x 17 mm | 133 x 80 x 19 mm |
| Interfaces | ||
| USB interface | 4x USB 2.0 - connector type a |
2x USB 2.0, connector type a 1x USB 3.0 connector type a 1x USB 3.0 connector a type C host |
| Network interface | Ethernet port 10/1000 Mbps | Ethernet port 10/100/1000 Mbit / s |
| Wi-Fi Interface |
Dual Band (2.4 GHz and 5 GHz 802.11 b/g/n/ac |
no dedicated plug |
| Bluetooth | Low Energy, BLE 4.1 | no dedicated plug |
| Camera | CSI connector | CSI connector |
| Touchscreen display | connector for DSI | connector for DSI |
| Video | HDMI HD 1080px / 30 fps | 4K (3820 x 2160 px) |
| Link | UART, SPI, I2C, GPIO |
UART, SPI, I2C, GPIO, I2S, S/PDIF |
| Additional |
PCI-e 2.1 |
|
