Siglent · 4 products

Siglent is a Chinese manufacturer of electronic measuring equipment: oscilloscopes, generators, power supplies, multimeters and spectrum analyzers. At Botland you will find digital oscilloscopes, e.g. SDS1104X-E and SDS1202X-E, and the SDG1062X Plus function generator. Choose them for an electronics workshop, service work and learning measurement. Check the full offer of the brand.

Siglent: digital oscilloscopes and function generators

Siglent is a brand owned by Siglent Technologies, a Chinese manufacturer of electronic measuring equipment. The manufacturer's range includes oscilloscopes, generators, power supplies, multimeters and spectrum analyzers. At Botland you will find mainly the brand's benchtop oscilloscopes and function generators. Based on them, you can put together a basic station for starting up and testing electronic circuits.

Siglent digital oscilloscope: how to choose a model

When choosing a digital oscilloscope, pay attention to two parameters: bandwidth and number of channels. Bandwidth tells you how fast the signals are that you can measure reliably. The number of channels determines how many waveforms you can view at the same time. Botland offers, for example, these models:

• Siglent SDS1104X-E: 100 MHz bandwidth and 4 channels
• Siglent SDS1202X-E: 200 MHz bandwidth and 2 channels
• Siglent SDS1102CML+: two-channel digital oscilloscope with 100 MHz bandwidth

Four channels will come in handy when you compare several signals at once, for example data lines and a clock signal. If you more often measure faster waveforms in simpler circuits, consider a model with higher bandwidth and two channels. You can check the full parameters of each model on its product page.

Siglent SDG1062X Plus function generator

A function generator produces test signals that you feed to the input of the circuit under test. You then observe the circuit's response on an oscilloscope. The Siglent SDG1062X Plus has 60 MHz bandwidth and two channels. Two channels let you prepare two signals at once, which makes it easier to test circuits with several inputs. Choose this generator when you need a stable signal source for learning, prototyping or service work.

How to put together a measurement station

An oscilloscope and a generator are enough for a basic workshop. The generator feeds a signal to the circuit under test, and the oscilloscope shows how that circuit responds to it. Such a set makes it easier to check filters, amplifiers and simple digital circuits. Siglent also makes power supplies, multimeters and spectrum analyzers, so if needed you can expand your station with more devices from the same brand. You can check the current offer in the benchtop oscilloscopes category.

Frequently asked questions about Siglent

What is the difference between the Siglent SDS1104X-E and the SDS1202X-E?
The SDS1104X-E has 100 MHz bandwidth and 4 channels, while the SDS1202X-E has 200 MHz bandwidth and 2 channels. Choose the first one when you want to observe several signals at the same time. The second one will work well when higher bandwidth matters more.

Which Siglent digital oscilloscope should I choose for a home workshop?
Start with bandwidth and number of channels, because they have the greatest influence on the range of measurements. Compare the models in the oscilloscopes category and check the full parameters on the product pages.

What is the Siglent SDG1062X Plus function generator used for?
It generates test signals that you feed to the input of the circuit under test. It has 60 MHz bandwidth and two channels. You can view the circuit's response on an oscilloscope, so the two devices complement each other well. See also other function generators in the store's offer.
