Argon ONE M.2 SATA expansion board - for Raspberry Pi 4B

Index: ARG-18766 EAN: 6709249470592
5
(10)
Ask a question
Argon One M.2 is an expansion board for Argon One cases. It allows you to run your Raspberry Pi using an M.2 SATA SSD, which provides faster boot up and more capacity. It accepts any size of M.2 SATA SSD with Key-B or Key-B and M Supports UASP to maximize the data transfer of the minicomputer. To use the board, replace the bottom of the Argon One case with the Argon One M.2 expansion board.
Argon ONE M.2 SATA expansion board - for Raspberry Pi 4B
€27.90
€22.68 tax excl.
Check quantity
Available
Shipping in 24 hours
Free shipping
30 days to return
PayPal payment
Check quantity
Manufacturer: Argon40
Compatibility: Raspberry Pi

Product description: Argon One M.2 SATA expansion board for Raspberry Pi 4B

Argon One M.2 is an expansion board for Argon One cases. It allows you to run your Raspberry Pi using anM.2 SATA SSD, which providesfaster boot upandmore capacity. It accepts any size of M.2 SATA SSD with Key-B or Key-B and M SupportsUASPtomaximize the data transfer ofthe minicomputer. To use the board, replace the bottom of the Argon One case with the Argon One M.2 expansion board.

Płytka rozszerzeń Argon One M.2 do Raspberry Pi 4B. Argon One M.2 expansion board for Raspberry Pi 4B.
Zestaw nie zawiera obudowy Argon One i Raspberry Pi 4B. TheArgon Onechassis andRaspberry Pi 4Bare not included in this kit.

Technical specifications

  • Expansion board for Raspberry Pi 4B and Argon One chassis
  • Communication protocol: UASP
  • Transfer rate: up to 6 Gb/s
  • Chipset: ASM1153E
  • Disk size: SSD M.2 2280 / 2260 / 2242 / 2230

Kit contents

  • Argon One M.2 expansion board
  • Mounting hardware
  • English user manual
Package width 9.5 cm
Package height 2 cm
Package depth 13 cm
Package weight 0.1 kg
Send us your question

Łukasz

05/04/22
Question: Good day, I have this question will the following drive fit into this case? https://www.x-kom.pl/p/477778-dysk-ssd-samsung-500gb-m2-pcie-nvme-970-evo-plus.html Greetings.
Answer: Unfortunately, this drive is not compatible.
Compatible drives are M.2 SATA with B or B+M key, they cannot be PCIe or NVMe :
https://www.jeffgeerling.com/blog/2021/argon-one-m2-raspberry-pi-ssd-case-review
Krzysztof

11/29/21
Question: I would like to purchase a RassberyPi 4B 8G + 2 band WiFi and an Argon chassis for Rasberry Pi along with a module to hook up M2 drives. Please help me and give me a list of items to order. In addition, please let me know what type and size of M2 drives I can connect.
Answer: Only SSDs with M.2 Key-B or Key-B and M connector of any size can be connected to the chassis.
https://botland.com.pl/moduly-i-zestawy-raspberry-pi-4b/16579-raspberry-pi-4-model-b-wifi-dualband-bluetooth-8gb-ram-15ghz-765756931199.html
https://botland.com.pl/obudowy-do-raspberry-pi-4b/17273-obudowa-do-raspberry-pi-4b-aluminiowa-z-wentylatorem-argon-one-m2-szara-5904422328597.html

Product reviews

Argon ONE M.2 SATA expansion board - for Raspberry Pi 4B

5/5

Average grade

10

Customers opinion
The following opinions are collected
and verified by
an external partner Trustmate
and come from the post-purchase process.
Jakub 24.04.2024 Confirmed purchase Translated review
Great extension for rpi4, faster operation of the entire system using an SSD instead of an SD card as well as greater security of the data carrier
Małgorzata 05.02.2024 Confirmed purchase Translated review
Okay okay
Bartosz K. 30.06.2022 Confirmed purchase Translated review
Remember that if you use additional external drives, you need an active usb hub!
Marcin C. 01.06.2022 Confirmed purchase Translated review
It works. How do I use the product? I use it as intended. Who would I recommend the product to? Users of the matching housing. What do I think about the quality of the product? Properly made, well dimensioned.
Paweł K. 13.12.2021 Confirmed purchase Translated review
An essential argon one raspberry pi extension
Robert C. 24.07.2021 Confirmed purchase Translated review
A great solution for the Argon enclosure.
Przemysław H. 22.07.2021 Confirmed purchase Translated review
Works great with the Argon case. I recommend.
Jarosław S. 17.02.2021 Confirmed purchase Translated review
The expansion board works very well. With the current firmware version for Raspberry PI 4, the system can easily get up from the disk without removing the microSD card. After installing this extension, there is no easy access to the microSD card and every time you need to disassemble everything if you want to remove / insert the card. One disadvantage is the lack of a LED informing about the operation of the disk, although there is a place for it on the board (versions 1.3 and 1.4 do not have this LED - marked on the PCB).
Michael 18.12.2023 Confirmed purchase
Romuald 11.04.2023 Confirmed purchase
