Product description: Shelly Plus 0-10V Dimmer - intelligent WiFi light dimmer
Shelly Plus 0-10V Dimmer allows you to precisely control the brightness of voltage-controlled lighting in the range from 0 V to 10 V. The controller can be successfully used with traditional wall switches . It does not require a gateway, for proper operation all you need is the Shelly Smart Control application or other platforms or voice assistants, including: Alexa, Home Assistant . The device also serves as a WiFi amplifier and Bluetooth gateway for other Shelly devices, thanks to the ESP32 module. Supports Webhooks, MQTT, WebSocket, HTTPS, UDP, TLS and custom certificates.
Shelly Plus 0-10V Dimmer - intelligent WiFi light dimmer.
Intelligent light dimmer 0 - 10 VMain features of the Shelly Pro 0-10V dimmer
- WiFi: Connect the Shelly Pro 0-10V Dimmer to your home WiFi network without the need for additional gateways.
- Bluetooth : quickly connect to your device via Bluetooth or use the module as a Bluetooth gateway for other devices.
- Smart Schedule : Set a schedule based on your daily schedule or schedule it to control the lighting according to sunrise/sunset.
- Flexible control methods: use existing switches, it doesn't matter whether they are single- or double-keyed.
- Smart Scenes: Shelly Plus 0-10V Dimmer combined with other Shelly devices allows you to create custom scenes.
- Scripts : Shelly Plus 0-10V Dimmer allows you to create your own scripts for custom functionalities.
Adjust the brightness to your actions
Brighten and dim depending on your activity during the day. Together with Shelly Pro 0-10V Dimmer, you will be able to set the lowest and highest brightness levels of lighting in your room. The controller will smoothly change the ambient lighting depending on whether you want to relax in the evening or focus on demanding tasks. Thanks to the possibility of control using a voice assistant, you do not have to reach for your phone with the application installed, just say the appropriate voice command.
Personalized lighting schedule
Shelly Pro 0-10V Dimmer will easily fit into your daily schedule . Children usually prefer to fall asleep with the light on, so you can use the Shelly controller to slightly dim the lighting in the children's room at a specific time, and then turn off the light completely after some time. Thanks to this, your baby will sleep peacefully and you will not worry about the energy consumed.
Create the right mood
The Shelly dimmer has pre-configured light scenes that you can easily activate with a voice command to quickly change the lighting in your room. Would you like to watch a movie? Just say "Movie night" to your Alexa and your space will instantly adjust, creating the perfect atmosphere for a cinematic experience.
Shelly Pro 0-10V Dimmer has ready-made scenes.
Night mode
Stop irritating your sleepy eyes with strong light when going to the toilet at night. Shelly Pro 0-10V Dimmer will ensure that the light brightness is set to a low level during set night hours.
Shelly Pro 0-10V Dimmer Specifications
- Supply voltage: 110 V to 240 V AC
- Power consumption: up to 1.2 W
- Neutral wire: not required
- Type of control: voltage 0 - 10 V (sinking)
- Maximum control voltage: 10 V DC
- Maximum control current: 0.35 W
- Built-in temperature sensor
- WiFi:
- WiFi protocol: 802.11 b/g/n
- WiFi range: up to 30 m indoors and up to 50 m outdoors (depending on local conditions)
- Maximum RF power: up to 20 dBm
- RF band: from 2401 MHz to 2495 MHz
- Bluetooth:
- Bluetooth standard: 4.2
- Bluetooth range: up to 10 m indoors and up to 30 m outdoors (depending on local conditions)
- Maximum RF power: up to 4 dBm
- RF band: from 2400 MHz to 2483.5 MHz
- Chip: ESP32 4MB Flash
- Number of schedules: 20
- Number of Webhooks (URL actions) 20 out of 5 URL per hook
- MQTT: yes
- Scripts: yes
- Operating temperature: from -20°C to 40°C
- Operating humidity: 30% to 70% RH
- Maximum altitude: 2000 m
- Maximum tightening torque of screw connections: 0.4 Nm
- Maximum wire cross-section: 0.2 mm2 to 2.5 mm2 / 24 AWG to 14 AWG
- Stripped wire length: 5 mm to 6 mm
- Installation: recessed
- Material: plastic
- Color: housing 2716C, black print
- Dimensions: 42 x 37 x 17 mm
- Weight: 17 g
