Product description: Tuya - presence and brightness sensor - ZigBee - Android / iOS application - OXT T160
The OXT sensor uses Doppler radar to precisely detect presence , registering even the smallest movements, such as breathing. This means that the light will not turn off while taking a shower or sitting still in the room. The built-in brightness sensor allows you to create automations based on light intensity, allowing you to adjust the lighting to current conditions. The device communicates using the ZigBee protocol, which ensures a stable connection and low energy consumption. Thanks to integration with the Tuya app, it is possible to remotely control the lighting and configure advanced automation scenarios.
<
Tuya - presence and brightness sensor - ZigBee - Android / iOS application - OXT T150.
The OXT sensor uses Doppler radar to precisely detect presence, recording even the smallest movements such as breathing.Special features of the sensor
- Detection of minute movements with Doppler radar technology - detects even the smallest movements, such as breathing or slight movements. This allows the light to remain on in situations where traditional PIR sensors might not work, such as when reading a book or working at a desk
- Two detection zones: near and far - the near zone registers micro-movements within a radius of several meters, ideal for interiors such as offices, bathrooms or bedrooms. The far zone allows for detecting movement at a distance of up to 10 meters, which works well in corridors or garages
- Ability to pass through obstacles - radar detection mechanism allows for detection of presence behind obstacles such as glass partitions or thin walls
- Built-in brightness sensor - By precisely measuring the ambient brightness, the sensor adjusts its operation depending on the light conditions. It automatically turns on the lighting only when it is needed, which significantly increases energy savings
Full support for the Tuya Smart application
The presence and brightness sensor offers full integration with the Tuya Smart app, making it a functional and easy-to-use solution for lighting automation and monitoring ambient parameters. The Tuya Smart app, available for free on Google Play and the App Store , allows you to remotely control the device and adjust its operation to individual needs.
Thanks to the intuitive application interface you can:
- create advanced automation scenarios
- manage detection sensitivity settings
- configure the device's response to changes in ambient brightness
- monitor real-time activity data
The device communicates using the ZigBee protocol, which ensures a stable connection and low energy consumption.
ZigBee technology .
ZigBee technology
ZigBee technology is a communication standard that allows several devices to connect at the same time. It enables the creation of a smart home and makes it easier to control it, e.g. by switching on an alarm signal or lighting based on a temperature and humidity sensor when the previously specified optimal range is exceeded. The mesh topology ensures stable communication between the central unit and individual elements of the system, because each receiver is also a transmitter. Damage to one device does not result in the entire network stopping.
Sensor Technical Specifications
- Communication protocol: ZigBee
- Power supply: AC 230 V
- Detection angle: 120° (ceiling mount)
- Detection distance: 0 m to 9.5 m
- Illuminance measurement range: 0 lux to 2000 lux
- Operating frequency: 5800 MHz
- Degree of protection: IP20
- Dimensions: 39 x 62 x 62 mm
Kit Contents
- OXT T150 Presence and Brightness Sensor
- Mounting elements
Thanks to integration with the Tuya application, it is possible to remotely control lighting and configure advanced automation scenarios.
