Product description: Fiberlogy ASA filament 1.75 mm 1 kg - Gray
ASA filament is characterized by high durability, ease of printing , and color stability . It is widely used in automotive, electronics, and everyday printing applications. The material does not require a heated chamber to ensure successful printing. ASA can be treated with acetone, making the printed layers invisible. The material is sandable and paintable. The product is gray and pre-wound on a spool. Net weight: 1 kg .
Our range of filaments also includes other materials and colors.
Fiberlogy ASA filament 1.75 mm 1 kg - Gray .
Properties of Fiberlogy ASA filament
- Versatile use thanks to high print durability
- Used for printing sports accessories, interior design elements, as well as car and motorcycle parts.
- Resistant to the effects of ultraviolet UV radiation
- Compared to other types of filaments, ASA material does not emit such an unpleasant odor as the others
- It has significantly less shrinkage than ABS, eliminating the need for a heated print chamber. Increased adhesion prevents the model from "curling."
- It is characterized by very high color durability
- Resistant to high temperatures, up to 94 °C
- Models printed from ASA filament can be smoothed, sanded, painted or glued.
Printing Tips
- Printing with ASA filament does not require the use of a closed build chamber
- Suggested airflow values: up to 25%
- Flowrate parameter value: from 90% to 100%
- Base type: glass, kapton tape
- Retraction settings:
- for Direct extruders: 1 to 2 mm
- for Bowden extruders: 4 to 6 mm
- Suggested retraction speed: 20 to 45 m/s
- When printing in a chamber that is not heated, it is recommended to avoid drafts and sudden gusts of air
Fiberlogy ASA filament properties chart.
Suggested filament printing parameters
| Printing temperature: | from 255°C to 270°C |
| Table temperature: | from 90°C to 110°C |
| Print speed: | up to 100 mm/s |
Due to differences in printer design, the above data should be treated as guidelines and the appropriate values should be determined experimentally. |
ASA filament specification
| Parameter | Range |
|---|---|
| Filament diameter: | 1.75 mm |
| Filament dimensional tolerance | +/- 0.02 mm |
| Color | gray |
| Printing temperature | from 255°C to 270°C |
| Table temperature | from 90 °C to 110 °C |
| Material | acrylonitrile - styrene - acrylate (ASA) |
| Spool diameter | 200 mm |
| Spool width | 58 mm |
| Mounting hole diameter | 54 mm |
| Moisture absorber | Yes |
| Vacuum packaging | Yes |
| Roundness | +/- 0.01 mm |
| Package dimensions | 205 x 205 x 90 mm |
| Net weight | 1 kg |
Filaments are hygroscopic (they absorb moisture), so breaching the airtight vacuum packaging permanently reduces the quality and value of the product. Therefore, if you return an unpacked item, your refund amount will be reduced proportionally. Returns resulting from manufacturing defects (e.g., damaged or cut filament) are an exception. Please carefully verify the color and material type on the label before opening the packaging.
