Product description: Shelly Bypass - stabilizing module for installations without neutral wire - for Shelly 1L / Dimmer 2 / Shelly Dimmer Gen3
The Shelly Bypass is a compact installation module used in smart home systems based on Shelly devices. Its purpose is to ensure the correct operation of modules that do not require a neutral wire when the lighting circuit is under low load . This solution is particularly effective with modern, low-power LED lighting , where flickering or controller malfunctions may occur without a bypass. The module is compatible with Shelly 1L , Shelly Dimmer 2, and Shelly Dimmer Gen3 devices . Its compact size allows it to be mounted in a junction box along with the control module . The Shelly Bypass is suitable for use in residential buildings, commercial buildings, and public buildings.
Shelly Bypass - stabilizing module for installations without neutral wire - for Shelly 1L / Dimmer 2 / Shelly Dimmer Gen3.
Shelly Bypass has been designed to work seamlessly with controllers such as Shelly 1L and Shelly Dimmer 2.
Shelly Bypass Main Features
- Compatibility with Shelly devices : works with Shelly 1L, Shelly Dimmer 2 and Shelly Dimmer Gen3
- Support for installations without a neutral wire : allows Shelly modules to operate correctly at low loads
- Stable LED lighting : helps reduce flickering and unstable light source operation
- Compact design : small dimensions facilitate installation in an installation box
- Low energy consumption : power consumption less than 4 W
- Wide range of applications : suitable for homes, hotels, offices and small commercial premises
Shelly Bypass Technical Specifications
- Compatibility: Shelly 1L, Shelly Dimmer 2, Shelly Dimmer Gen3
- Operating voltage: 230 VAC
- Power consumption: < 4 W
- Operating temperature: -20°C to 70°C
- Operating humidity: 30% RH to 70% RH
- Maximum operating altitude: 2000 m above sea level
- Mounting: parallel to the load
- Material: plastic
- Color: white
- Dimensions: 39 x 23 x 13 mm
Kit contents
- 1x Shelly Bypass
