Power supply Mean Well MDR-20-24 for DIN rail - 24V / 1,0A / 24W
DIN rail mounted power supply unit. Input voltage from 85 V to 264 V AC and from 120 V to 370 V DC. Output voltage is 24 V. Output current up to 1.0 A.
We could not load the price.
The promotional price does not combine with quantity discounts.
Product description: Mean Well MDR-20-24 DIN rail mounted power supply - 24 V / 1 A / 24 W
DIN rail mounted powersupply. Input voltage: from 85 V to 264 V AC and from 120 V to 370 V DC. Output voltage is 24 V. Output current up to 1.0 A.
MDR-20-24 power supply specification
- Supply voltage:
- AC from 85 V to 264 V
- from 120 V to 370 V
- Type: impulse
- Output voltage: 24 V DC
- Output current: 1.0 A
- Power: 24 W
- Efficiency: above 80%
- DIN rail mounted
- Connections in the form of screw terminals
- Signalling the correct output voltage: NO contact
- Dimensions: 22.5 x 90 x 100 mm
- Weight: 170 g
Details in the documentation.
Mean Well MDR-20-24 DIN rail power supply - 24 V / 1 A / 24 W.
Compact 24 V DC power supply for DIN rail.
A small industrial power supply in a slim housing designed for DIN rail. The MDR-20-24 model operates with input voltages from 85 V to 264 V AC, as well as from 120 V to 370 V DC - so it is a very universal solution that can be used in various types of installations.
The maximum output current is 1 A and the rated output voltage is 24 V DC (24 W output power). Efficiency exceeds 80%. The most demanding applications will benefit from an additional DC OK output, signalled by a contact in NO (normally open) configuration.
Other parameters
The Mean Well MDR-20-24 DIN railpower supply - 24 V / 1 A / 24 W offers low ripple and noise (maximum 150 mVpp in a 20 MHz band), and the output voltage value tolerance is +/-1%. In AC mode, the power supply tolerates the input voltage frequency in the range of 47..63 Hz.
As befits an industrial-class power supply, the Mean Well MDR-20-24 has built-in overcurrent, short-circuit and overvoltage protections. The mounting bracket allows for installation on a standard TS-35 rail with a depth of 7,5 mm or 15 mm.
| Name | Value |
|---|---|
| Voltage output from | 24.0 V |
| Output voltage to | 24.0 V |
| Nominal output voltage | 24.0 V |
| Nominal power | 24 W |
| Current | 1 A |
| Power supply - type | for DIN rail |
| Power supply - Plug | ARK screw |
| Width | 10 cm |
| Height | 11 cm |
| Depth | 3 cm |
| Weight | 0.2 kg |
