Description
Digital monostable switch with 3-pin connector. It is powered with the voltage from 3.3 V to 5 V, it works with Arduino modules. The kit includes a cable adapted to DFRobot IO Expansion Shield.
|
The product is compatible with Arduino Sample code and detailed information can be found in the user guide. |
Connection
The module works with any microcontroller with digital inputs, including Arduino. To read data, just connect the power supply and output pin to any input of the microcontroller, and read its status.
Example of connecting the sensor with Arduino.
Specification
- Supply voltage: from 3.3 V to 5 V
- Communications: digital signal 0/1
- Built-in LED
- Color: green
- Cable for connection with DFRobot IO Expansion Shield
- Board sizes: 22 x 30 mm
Board is suitable for connectors of DFRobot IO Expansion Shield for Arduino V7.1.
Set includes:
- Digital bistable switch
- Connecting cable
