Product description: Argon ONE V5 Quad M.2 NVMe - expansion board for Raspberry Pi 5
The Argon ONE V5 Quad M.2 NVMe is an expansion board designed for Raspberry Pi 5 users who need larger storage and fast data access. It allows you to build a compact system with support for multiple NVMe SSDs , ideal for home servers, data warehouses, NAS systems, multimedia projects, and test environments.
The board supports M.2 NVMe M-Key drives, enabling the use of popular SSDs available on the market. Depending on the Raspberry Pi 5's PCIe interface variant and configuration, the module can achieve speeds of up to 500 MB/s per lane in PCIe Gen 2.0 mode or up to 1000 MB/s per lane in PCIe Gen 3.0 mode.
The product is offered as an expansion board only - without the Argon ONE V5 enclosure and without NVMe drives.
Argon ONE V5 Quad M.2 NVMe - expansion board for Raspberry Pi 5.
The Argon ONE V5 Quad M.2 NVMe is an expansion board designed for Raspberry Pi 5 users who need larger storage space and fast data access.
Technical features
- Support for four NVMe drives: The board allows you to expand your Raspberry Pi 5 with fast M.2 NVMe drives
- M-Key Compatibility: The module works with M.2 NVMe M-Key drives
- Support for drives up to 2280: supports media in the popular M.2 2280 format
- Fast data access: PCIe interface allows you to use high-performance SSDs in projects based on the Raspberry Pi 5
- PCIe Gen 2.0 and Gen 3.0 variants: speed depends on module version and Raspberry Pi 5 interface configuration
- Extension for Argon ONE V5: the board is intended for the expansion of sets based on the Argon ONE V5 housing
- For server applications: a good choice for NAS, file servers, backup systems and homelab projects
Practical applications
The Argon ONE V5 Quad M.2 NVMe is ideal for projects where the Raspberry Pi 5 will function as a compact data server, NAS system, backup center, or multimedia storage device. The ability to connect multiple NVMe drives significantly increases storage capacity and performance compared to a standard microSD card. The module will also be useful in test environments, home lab projects, surveillance systems, edge computing applications, and solutions requiring fast data read and write speeds. This is a practical extension for users who want to use the Raspberry Pi 5 for more advanced applications than a standard educational minicomputer.
Technical specifications
- Compatibility: Raspberry Pi 5, Argon ONE V5 case
- Supported drives: M.2 NVMe
- Disk Key: M-Key
- Maximum disk size: 2280
- Number of NVMe slots: 4
- Interface: PCIe
- Gen 2.0 speed: up to 500 MB/s per lane
- Gen 3.0 speed: up to 1000 MB/s per lane
- Examples of compatible drives: Argon Dataterm, Official Raspberry Pi SSD, Western Digital SN850, SN740, SN570, SN530, Samsung 980 Pro, Samsung 980, Sabrent Rocket, PNY CS1030, Lexar NM710, Lexar NM620, Kioxia Exceria, Kingston KC3000, Crucial P2, AData XPG SX8200 Pro
The board supports M.2 NVMe M-Key drives, allowing the use of popular SSD media available on the market.
