Power supply Mean Well HDR-60-12 for DIN rail - 12V / 4.5A / 54W
12 V and 54 W in a housing 3 modules wide: Mean Well HDR-60-12 DIN rail power supply for modular distribution boards.
- Input 85-264 V AC, adjustable output 10.8-13.8 V
- Current up to 4.5 A, efficiency typically 88%
- Insulation class II, fanless cooling
We could not load the price.
The promotional price does not combine with quantity discounts.
12 V from a power supply that takes up only three modules in the distribution board
Mean Well HDR-60-12 delivers 12 V and up to 4.5 A, which is 54 W, from a housing 52.5 mm wide, and its stepped shape fits modular distribution boards with a cover. The power supply sits in the same row as circuit breakers. You can use it to power home automation modules, sensors, controllers and relays with a 12 V coil.
You adjust the output voltage with a potentiometer in the range from 10.8 V to 13.8 V, which lets you compensate for voltage drop on longer cables. The power supply works from mains of 85 V to 264 V AC, has a typical efficiency of 88% and is cooled without a fan.
Mean Well HDR-60-12 power supply on a DIN rail
12 V / 4.5 A
rated power 54 W
52.5 mm
width equal to 3 modules on the DIN rail
10.8-13.8 V
voltage adjustment range
< 0.3 W
no-load power consumption
A good choice for you?
A good choice if:
- you need 12 V in a distribution board for automation or lighting
- the total current draw of your devices does not exceed 4.5 A
- you want a fanless power supply with no earth terminal (insulation class II)
Consider another option if:
- a lower current is enough: see the Mean Well HDR-30-12 power supply (12 V, 2 A)
- you need a 12 V power supply in a narrower housing: choose the Mean Well MDR-20-12 power supply
Technical specifications
| Parameter | Value |
|---|---|
| Type | switching power supply for DIN rail |
| Output voltage | 12 V DC, adjustable 10.8-13.8 V |
| Output current | 0-4.5 A |
| Rated power | 54 W |
| Ripple and noise | max. 120 mVp-p |
| Input voltage | 85-264 V AC (47-63 Hz) or 120-370 V DC |
| Efficiency | typically 88% |
| No-load power consumption | below 0.3 W |
| Protection | overload (105%-160% of power), short circuit, overvoltage (14.2-16.2 V) |
| Insulation class | II, limited power source (LPS) |
| Operating temperature | -30 °C to +70 °C (derating above approx. 45 °C) |
| Cooling | natural, fanless |
| Mounting | DIN rail TS35/7.5 or TS35/15 |
| Connectors | screw terminals: L, N, +V (2x), -V (2x) |
| Dimensions | 52.5 x 90 x 54.5 mm |
| Weight | 190 g |
| Manufacturer warranty | 3 years |
| Manufacturer | Mean Well |
Did you know?
Five factories on three continents
Mean Well manufactures power supplies at five sites: in New Taipei in Taiwan, in Guangzhou and Suzhou in China, in Bangalore in India and in Kansas City in the USA.
Source: Mean Well: Group Overview
Frequently asked questions
Can I use it to power a 12 V LED strip?
Yes, as long as the total power of the strip does not exceed 54 W, and ideally leave about 20% headroom. For longer runs you can raise the voltage to 13.8 V with the potentiometer to compensate for voltage drop on the cables.
Why does the power supply have no earth terminal?
The HDR-60-12 has insulation class II, meaning double insulation, and does not require a protective earth conductor. You only connect L and N on the mains side and +V and -V on the output side.
How many modules will it take up in the distribution board?
The power supply is 52.5 mm wide, which is three modules of 17.5 mm, and you mount it on a TS35 rail.
Useful links
| Name | Value |
|---|---|
| Voltage output from | 10.8 V |
| Output voltage to | 13.8 V |
| Nominal output voltage | 12.0 V |
| Nominal power | 54 W |
| Current | 4.5 A |
| Power supply - type | for DIN rail |
| Power supply - Plug | ARK screw |
| Weight | 0.22 kg |
