Power supply MDIN60W24 for DIN rail - 24V / 2.5A / 60W

Index: WAK-11427 EAN: 5902135123683

DIN rail mounted power supply unit. Input voltage from 90 V to 264 V AC. Output voltage is 24 V. The output current is 2.5 A. The rated power is 60 W.

Power supply MDIN60W24 for DIN rail - 24V / 2.5A / 60W
€20.50
€16.67 tax excl.
Available
Shipping in 24 hours
PayPal payment
Manufacturer: OEM

Product description: MDIN60W24 DIN rail mounted power supply - 24 V / 2,5 A / 60 W.

DIN rail mounted powersupply. Input voltage: from 90 V to 264 V AC. Output voltage is 24 V. The output current is 2.5 A. The nominal power is 60 W.

Zasilacz MDIN60W24 na szynę DIN - 24V / 2,5A / 60W MDIN60W24 DIN rail power supply - 24 V / 2.5 A / 60 W.

Specifications

  • Input voltage: AC from 90 V to 264 V
  • Type: constant voltage
  • Output voltage: 24 V DC
  • Output current: 2.5 A
  • Power: 60 W
  • Efficiency: over 82 %
  • DIN rail mounted
  • Connections in the form of screw terminals
  • Signalling the correct output voltage: DC contact OK
  • Protection: overload / short-circuit / overvoltage / thermal protection
  • Dimensions: 40 x 90 x 100 mm
  • Weight: 300 g

Details in the documentation.

Voltage output from 24.0 V
Output voltage to 24.0 V
Nominal output voltage 24.0 V
Nominal power 40 W
Current 2.5 A
Power supply - type for DIN rail
Power supply - Plug ARK screw
Package width 10.5 cm
Package height 4.5 cm
Package depth 11.5 cm
Package weight 0.3 kg
