Product description: Slit sensor of 2mm - Iduino
Digital module with optical sensorwith a slit of 2 mm. The output isa digital signal. The supply voltage is5 V. With the encoder's shield, it can be used as a device counting the pulses, etc.
Connecting the slit sensor
The sensor works withany microcontrollerwith digital inputs, includingArduino. To read data, it is sufficient to connect the power source and output pins to any input of the microcontroller and read its status.
Example of connecting toArduino.
| PIN | Description |
|---|---|
| - | The ground of the system. |
| +(central pin) | Power Supply of 5 V. |
| S | The output of the digital signal. |
Specification of the slit sensor nm
- Supply voltage: 5 V
- Output: digital
- Pins: 3-pin
- Slit width: 2 mm
- Dimensions: 28 x 15 mm
- Weight: 2 g
