Product description: Unit PoE-P4 - Ethernet PoE controller with ESP32-P4 and MIPI CSI/DSI - M5Stack U213
The Unit PoE-P4 is a high-performance embedded controller based on the ESP32-P4NRW32 chip with two 360 MHz RISC-V cores and an additional energy-efficient 40 MHz core. The module is equipped with 16 MB of Flash , 32 MB of PSRAM , and a 10/100 Mbps Ethernet controller with IEEE 802.3at PoE support, enabling simultaneous data and power transmission over a single Ethernet cable. The device offers MIPI DSI and MIPI CSI interfaces for displays and cameras, as well as USB Type-C Host and OTG ports, Grove, Hat2-Bus, SDIO, and ISP connectors . The built-in RGB LED , user button, and IR emitter make the module ideal for Smart Home systems, HMIs, edge computing, and IoT applications.
Unit PoE-P4 - Ethernet PoE controller with ESP32-P4 and MIPI CSI/DSI - M5Stack U213.
Unit PoE-P4 is an advanced network controller based on the ESP32-P4NRW32 chip.Special features
- High-performance ESP32-P4: Dual-core RISC-V 360MHz + LP 40MHz core
- Large memory: 16 MB Flash and 32 MB PSRAM
- PoE support: power and data transmission over a single Ethernet cable
- Ethernet 10/100 Mbps: integrated IP101GRI chip
- MIPI DSI interface: supports displays up to 1920 x 1080 px
- MIPI CSI interface: possibility of connecting cameras
- USB Type-C Host and OTG: Support for USB devices and programming
- Extensive interfaces: Grove, Hat2-Bus, SDIO and ISP
- RGB LED and IR: support for infrared signaling and transmission
- Ideal for IoT and HMI: Industrial, Smart Home and Edge Computing Applications
Technical specifications
- Model: Unit PoE-P4
- SoC: ESP32-P4NRW32
- Architecture: 2x RISC-V 32-bit 360 MHz, 1x RISC-V LP 40 MHz
- Flash memory: 16 MB
- PSRAM memory: 32 MB
- Power supply: USB Type-C 5V, PoE
- PoE standard: IEEE 802.3at
- Maximum PoE power: 6 W
- Ethernet Controller: IP101GRI
- Ethernet speed: 10/100 Mbps
- Ethernet connector: RJ45
- Display Interface: 24P FPC, MIPI DSI 2-Lane, TP+BL
- Maximum display resolution: 1920 x 1080 px
- Camera interface: 24P FPC, MIPI CSI 2-Lane
- USB: 1x USB Type-C Host USB 2.0, 1x USB Type-C OTG/Programming, USB 2.0
- Expansion interfaces: HY2.0-4P Grove, Hat2-Bus 2.54-16P, SDIO-Bus 2.56-9P, ISP-Bus 2.56-6P
- RGB LED: NH-B2020RGBA-HF
- IR Transmitter: MHS153IRCT
- Operating temperature: 0°C to 40°C
- Power consumption:
- Standard operation: 5 V / 73.82 mA
- full load: 277.10 mA
- deep sleep: 19.85 mA
- Weight: 28.2 g
- Dimensions: 64 x 24 x 20.2 mm
Practical applications
- M5Stack Unit PoE-P4
- Grove HY2.0-4P Cable 20 cm
The module has 16 MB of Flash memory and 32 MB of PSRAM, which ensures high performance when handling graphical interfaces, data processing, and edge AI and IoT applications.
