Power supply Mean Well HDR-30-24 for DIN rail - 24V / 1.5A / 36W
24 V and 36 W in a width of 2 modules: Mean Well HDR-30-24 DIN rail power supply.
- Input 85-264 V AC, adjustable output 21.6-29 V
- Current up to 1.5 A, efficiency typically 89%
- No-load consumption below 0.3 W
We could not load the price.
The promotional price does not combine with quantity discounts.
24 V in a housing two modules wide
Mean Well HDR-30-24 is a DIN rail power supply 35 mm wide, which is two modules. It delivers 24 V and up to 1.5 A, so 36 W, which is enough for a PLC controller, a few relays or sensors in a building installation. The stepped shape of the housing fits modular distribution boards with a cover.
The power supply works from mains of 85 V to 264 V AC as well as from DC voltage of 120 V to 370 V. You set the output voltage with a potentiometer from 21.6 V to 29 V, the efficiency is typically 89%, and with no load it draws less than 0.3 W.
Mean Well HDR-30-24 power supply on a DIN rail
24 V / 1.5 A
rated power 36 W
35 mm
width equal to 2 modules on a DIN rail
89%
typical efficiency
130 g
power supply weight
A good choice for you?
A good choice if:
- you need a small 24 V power supply for a distribution board that is short on space
- your devices draw up to 1.5 A in total
- you want to adjust the output voltage in the range of 21.6-29 V
Consider another option if:
- you need an even narrower 24 V power supply: see the Mean Well MDR-20-24 power supply
- you need more power: choose the MDIN100W24 power supply, 100 W
Technical specifications
| Parameter | Value |
|---|---|
| Type | switching power supply for DIN rail |
| Output voltage | 24 V DC, adjustable 21.6-29 V |
| Output current | 0-1.5 A |
| Rated power | 36 W |
| Ripple and noise | max. 150 mVp-p |
| Input voltage | 85-264 V AC (47-63 Hz) or 120-370 V DC |
| Efficiency | typically 89% |
| No-load power consumption | below 0.3 W |
| Protection | overload (105%-160% of power), short circuit, overvoltage (30-36 V) |
| Insulation class | II, limited power source (LPS) |
| Operating temperature | -30 °C to +70 °C (derating above 50 °C) |
| Cooling | natural, fanless |
| Mounting | DIN rail TS35/7.5 or TS35/15 |
| Connectors | screw terminals: L, N, +V, -V |
| Dimensions | 35 x 90 x 54.5 mm |
| Weight | 130 g |
| Manufacturer warranty | 3 years |
| Manufacturer | Mean Well |
Did you know?
A leading manufacturer
According to a Micro Technology report from April 2026, Mean Well ranks 5th among DC output power supply manufacturers worldwide. Unlike the companies in the top four, it earns almost all of its revenue from standard power supplies under its own brand.
Source: Mean Well: Group Overview
Frequently asked questions
Will the power supply restart by itself after a short circuit?
Yes. In case of a short circuit or overload the power supply limits the current or enters hiccup mode, and after the cause is removed it resumes operation without switching the power off. The exception is when the overvoltage protection trips, after which you must switch the power off and on again.
Can I use it to power a 24 V PLC controller?
Yes, if the current draw of the controller together with its modules and sensors does not exceed 1.5 A. For a larger installation, choose a power supply with higher power.
What rail can I mount it on?
On a standard TS35 rail, both 7.5 mm and 15 mm high.
Useful links
| Name | Value |
|---|---|
| Voltage output from | 21.6 V |
| Output voltage to | 29.0 V |
| Nominal output voltage | 24.0 V |
| Nominal power | 36 W |
| Current | 1.5 A |
| Power supply - type | for DIN rail |
| Power supply - Plug | ARK screw |
| Width | 9.8 cm |
| Height | 6.5 cm |
| Depth | 4 cm |
| Weight | 0.1 kg |
